SDM-S100E Live Video Streaming and Recording Module Card, 60 Hz
Please sign in so that we can notify you about a reply
The SDM-S100E module card provides high performance of H.264/265 live video streaming and recording, which transmits 4K30 video signal over standard Gigabit Ethernet. Video output resolution can be up to 4K30; it is a standard quality for streaming. The unit supports RTSP/TCP/UDP/RTMP protocols. All video content is encoded and streamed with minimal latency, making it ideal for live streaming on a variety of popular platforms or within the local network. The video may also be recorded locally (via USB thumb drive) or to a local network drive while it is being streamed.
Features- Supports live streaming on Facebook, YouTube or Twitch channels
- 4K30 4:4:4 video signal over standard Gigabit Ethernet
- Recorded video can be stored locally at connected USB storage (FAT or exFAT format) or to a designated network drive supporting NFS or CIFS
Brand:
Cypress Technology
Product Type:
Video Streaming & Recording Module Card
Specifications
Maximum Operating Temperature:
+40°C
Number of Channels:
USB Sample Rate:
48kHz
Power Rating:
15W
Applications:
Webcasting, Social Media Broadcasting, Live Event Streaming, Video on Demand Streaming, Live Recording and Storage
Minimum Operating Temperature:
0°C
Includes:
1xH.264/265 Live Video Streaming and Recording Module Card, 1xOperation Manual
Performance
Frequency Rating:
60Hz
Sample Rate:
48kHz
USB Bit Depth:
8bit, 10/12bit
Inputs and Ports
Connector Type:
Input: 1xCYP Module, Output: 1xLAN (RJ-45), 1xUSB 2.0 (Type-A)
Number of Ports:
2
Dimensions
Width:
12.8cm
Depth:
2.5cm
Height:
7.9cm
Weight:
300g
