CUSB-V605H UHD+ HDMI to USB Video Capture Recorder with PIP
Please sign in so that we can notify you about a reply
This HDMI to USB video capture recorder with HDMI bypass can support resolutions up to 18Gbps (600MHz) 4K UHD with HDR (via the bypass path) while simultaneously streaming the audio and video signal at 1080p to a USB connected PC for capture or re-broadcast. Also with add up input special video timing stabilization feature helps to ensure that the USB capture stream won’t lock up or drop, even if the HDMI input source is intermittent or disconnected. This makes your live streaming stable and non-stop.
Features
- 2 inputs(input 1 resolution up to 4K@60, input 2 up to 1080p@60), 1 bypass output (Follow source up to 4K@60
- USB3.0 (Type-B to Type-A) connected to PC for data transmission
- 3.5mm phone jack as Input of speaker
- Mode select button is designed for changing the layout of video sources, which allow user to define on tool
- Audio auto switch for priorities audio insertion or default priority
- Audio Mixer for provide flexible audio feature for mixing analog mic in with HDMI input audio
- PC software available for detail control and setting
Brand:
Cypress Technology
Product Type:
UHD+HDMI to USB Video Capture Box with PIP
Specifications
Maximum Operating Temperature:
+40°C
Colour:
Black
Special Features:
Connected to PC for Data Transmission, Mode Select Button is Designed for Changing the Layout of Video Sources
Power Rating:
4.5W
Chassis Material:
Steel
Applications:
Live Video Stream Recording for Broadcast, Security Camera Recording, Gameplay Video Archival
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
OBS (Open Broadcaster Software) Streaming Software which is Available for Windows PC, MacOS and Linux
Performance
HDMI Compliance Type:
2.0 (DVI 1.0)
HDCP Compliance Type:
2.2
Output Signal Type:
4K@60Hz 8bit YUV 4:4:4 (HDMI), 1080pixels@60Hz (USB capture)
Inputs and Ports
Input Port Type:
2xHDMI-Type A, 1xAnalog (3.5mm)
Output Port Type:
1xHDMI-Type A, 1xUSB 3.0-Type B
Number of Ports:
5
Input Signal Type:
4K@60Hz 8bits YUV 4:4:4
Dimensions
Width:
18cm
Depth:
10.8cm
Height:
2.5cm
Weight:
916g
