CUSB-603 HDMI/Component Video/SV/CV to USB Video Capture
Please sign in so that we can notify you about a reply
The CUSB-603 is High Definition capture box supports HDMI 1080p video/component/SV/CVinput and record to H.264 video format. Its low power consumption and superior video processing capabilities make it ideal for integration into high-end portable and desk top PC products.
Features- Supports Full HD capture of HDMI/COMP/SV/CV signal to USB
- Built-in H.264/MPEG4-AVC High Definition encoder
- Video input Supports input video timings: 1920 x 1080, 1280 x 720, 576, 720 x 480
- Supports MPEG-4 Advanced Audio Coding (AAC)
- Supports audio sampling frequency of 48 KHz
- Powered via USB bus power with low power consumption
Brand:
Cypress Technology
Product Type:
HDMI/COMP/SV/CV to USB FullHD Capture Box
Specifications
Maximum Operating Temperature:
+40°C
Colour:
Black
Special Features:
Supports Full HD Capture of HDMI/COMP/SV/CV Signal to USB, Built-in H.264/MPEG4-AVC High Definition Encoder, Supports MPEG-4 Advanced Audio Coding (AAC)
Power Rating:
2.5W
Applications:
Displaying HD Signal on PC or NB’s Monitor
Material:
Aluminium
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Dimensions
Width:
6.55cm
Depth:
12.1cm
Height:
2.2cm
Weight:
146g
Other
Voltage Rating:
5V DC
Standards Met:
CE, ISO 9001, ISO 14001, OHSAS 18001
