MV-6 3G HD-SDI Multiviewer
Please sign in so that we can notify you about a reply
The MV−6 is a versatile, high−performance multiviewer for 3G HD−SDI video signals. The device can display up to six inputs in any combination and output the image in SDI, HDMI and CV formats. Both pre−programmed and customizable screen divisions are supported. The MV−6−MD is certified for medical applications.
Features
- Max. Data Rate — 3Gbps.
- HDTV Compatible.
- Standards Compliance — Certified for medical applications according to IEC 60601–1–2 (Electromagnetic Compatibility).
- Kramer re–Klocking™ & Equalization Technology — Rebuilds the digital signal to travel longer distances.
- Multi–Standard Operation — SDI (SMPTE 259M), HD–SDI (SMPTE 292M) and 3G HD–SDI (SMPTE 424M).
- Re–Clocking Looping Inputs.
- Multi–Video Output Formats — 3G HD–SDI (SMPTE 424M), HDMI and composite, scaling, refresh rate and video standard conversion.
- Front Panel Preview Screen — 16:9 4.3in color LCD displaying the output of the unit.
- Text Overlay — A text label/icon can be added inside each window. Each label has text/background color, alignment, size, etc settings.
- Screen Handling Buttons — Freeze, size, position, and 4 pre–programmed and 2 user–definable layouts.
- Flexible Control Options — Front panel with 2–row LCD, OSD, Ethernet & RS–232 (supplied with PC control software).
- Worldwide Power Supply — 100–240V AC.
- Medically Certified Version — Contact your local Kramer representative for details.
Brand:
Kramer
Part number:
60-71002030
Product Type:
3G HD-SDI Multiviewer
Specifications
Maximum Operating Temperature:
+40°C
Colour:
Black
Auto Switching Type:
3G HD-SDI
Control Type:
Front Panel Button, RS-232, Ethernet
Version:
220V
Special Features:
Re-Clocking Looping Inputs, Text Overlay, Medically Certified Version
Front Panel Display Type:
LCD
Power Rating:
35VA
Applications:
Professional Broadcasting and Production Studios, Presentation, Post-Production
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Includes:
Power Cord, Rack ”Ears”
Performance
Maximum Input Resolution:
800mVpp/75Ω
Maximum Output Resolution:
800mVpp/75Ω
Colour Space:
SD/HD/3G HD-SDI for Input, HDMI for Output
Frequency Rating:
50/60Hz
Data Transfer Rate:
Up to 2.97Gbps
Inputs and Ports
Input Port Type:
6xSD/HD/3G HD-SDI with Loop on BNC Connector
Output Port Type:
1xHDMI, 1xCV on a BNC Connector (For 720pixels@50Hz and 1920pixels@50Hz the Output is PAL, For 720pixels@59.94/60Hz and 1920pixels@59.94/60Hz the Output is NTSC), 1HD/3G HD-SDI on a BNC Connector
Dimensions
Width:
43.6cm
Depth:
18.4cm
Height:
8.8cm
Weight:
3.1kg
Other
Voltage Rating:
100 to 240V
Standards Met:
IEC 60601-1-2
