UMCE10N-N KVM Extender, USB Type-A/Type-B 2.0
Please sign in so that we can notify you about a reply
Enable long-distance extension of computer video, audio, keyboard/mouse, and IR remote signals, using high performance HDBaseT technology.
Features- Enable long-distance extension of computer video, audio, keyboard/ mouse, and IR remote signals, using high performance HDBaseT technology
- Unique dual connector supporting both DP and HDMI and allowing DP sources to be connected to HDMI displays and vice versa
- Video quality of 4K@30HZ 4:4:4 extension of up to 100m for copper models and 10km for Fiber models
- Fully USB 2.0 only extenders (UMCE10N-N) to extend and power any USB 2.0 device including webcams and other demanding devices
- Support for POE in Copper models allowing the use of a single PSU to power both RX and TX.
Brand:
HSL
Specifications
Product Type:
KVM Extender
Maximum Operating Temperature:
+40°C
USB Connection Type:
USB 2.0 Type-A, USB 2.0 Type-B
Supported Operating Systems:
Windows, Linux, Mac
Maximum Storage Temperature:
+60°C
Minimum Storage Temperature:
-20°C
Humidity:
0 to 80%
Minimum Operating Temperature:
0°C
Performance
Baud Rate:
1.25Gbps
Maximum Transmission Distance:
10km
Inputs and Ports
System Link Output:
RJ45
System Link Input:
RJ45
Connectivity
Emulation:
USB
Dimensions
Width:
2.8cm
Depth:
6cm
Height:
1.7cm
Weight:
0.02kg
Other
Standards Met:
CE, RCM, FCC Class B, VCCI, TUV US, TUV Canada
