IED5404CS-H PTT Digital Microphone Station, Black, 48V DC
Please sign in so that we can notify you about a reply
The AtlasIED 5404CS digital microphone station is a 4-button device for initiating audio / visual announcements, messages and pages with the 5400ACS Announcement Control Systems. Just like AtlasIED’s other digital microphone stations, the 5404CS uses a single Ethernet interface for audio and control data. The 5404CS is fully compatible with IEEE 802.3af standard for Power over Ethernet (PoE), allowing the microphone station to be powered directly from any standard off-the-shelf PoE switch. The 5404CS utilizes Dante™ technology for transporting high-quality, low-latency digital audio over Ethernet. The 5404CS microphone station may be used as part of an EN54-16 listed life safety system; although the mic stations themselves are not EN 54-16 listed and cannot be used for the emergency locations. Instead, in a dual-use system, these microphone stations may be used for everyday paging functions.
Features- Immediate Digitization of Full Bandwidth Audio
- Digital Audio Transmission Over Standard Ethernet Connection
- Mounts Using Standard 1- or 2-Gang Electrical Box
- Power, Busy, and Ready LED Indicators
Brand:
Atlas IED
Product Type:
Microphone Station
Specifications
Compression Threshold:
-14dBu
Mounting Type:
2-Gang Electrical Box
Colour:
Black
Series:
5400
Power Rating:
<4W
Operating Temperature Range:
0 TO +40°C
Performance
Attack Time:
35ms
Release Time:
0.5s
Signal-to-Noise Ratio:
>85dB
Frequency Rating:
22Hz to 22kHz
Total Harmonic Distortion:
<1%
Sample Rate:
48kHz
Power
PoE Supply Voltage:
48V DC
Dimensions
Width:
12.5cm
Depth:
4.8cm
Height:
12.5cm
Other
Voltage Rating:
48V DC
Standards Met:
EN54-16, IEEE 802.3
No reviews found
