HPA602 Dual-Channel, 600-Watt Commercial Amplifier
Please sign in so that we can notify you about a reply
The AtlasIED High Power Amplifier “HPA” Series is designed for use in both commercial 70V/100V distributed systems and professional applications that require amplifiers to handle multiple impedance loads. The HPA is compact and lightweight in comparison to other models delivering similar power levels. The HPA Series features Generation II Class D Output topology that provides great efficiency with the sound quality of a Class AB amplifier. The power supply is a switch mode, global auto sensing design that maintains a stable output during fluctuating power conditions. The power supply and output stage collectively are designed to deliver exceptional dynamic high output voltage and current to virtually any speaker load.The HPA Series features front panel detente level controls with a security cover, remote turn on, balanced inputs, fault reporting and a rear panel accessory card slot for an optional Dante™ 2 or 4-channel digital audio interface. HPA Series amplifiers feature a unique output stage, low resistance direct coupled thermal transfer design that effectively maintains optimal temperature across all loads and output levels. HPA Series amplifiers are also energy efficient and meet Energy Star standards, drawing only 1W of power in standby mode.Whether the application is a large distributed constant voltage sound system or a high SPL sound reinforcement system, the AtlasIED HPA Series is the answer for high power/cost effective amplification needs.
Features- 4Ω, 8Ω, 70.7V, & 100V Operation
- Balanced Inputs Euro Block Phoenix Style Connector
- Accessory Card Slot for Optional Dante™ Digital Network Audio Card
- Short-Circuit, Temperature, and DC Offset Protection
- Auto Sensing 100V-240V~ AC Mains Power Supply
- Stepped Attenuatorsw with Security Covers
Brand:
Atlas IED
Product Type:
Power Amplifier
Specifications
Number of Channels:
Special Features:
PoE Powered, Input Signal & Peak LED Indicator
Applications:
Distributed System, Professional High Performance Sound Reinforcement, Night Club, House of Worship System, Portable Sound System, Convention Center, Sports Venue, Hotel, Retail Centers
Indicator Type:
LED
Performance
Amplifier Class:
Class D
Signal-to-Noise Ratio:
>70dB
Frequency Rating:
20Hz to 20KHz
Input Impedance Rating:
20kΩ (Balanced), 10kΩ (Unbalanced)
Input Sensitivity:
0.775V, 1.0V, 32dB (Selectable)
Inputs and Ports
Number of Ports:
5
Dimensions
Width:
48.3cm
Depth:
26.1cm
Height:
8.9cm
Weight:
6.7kg
Shipping Weight:
8.1kg
Other
Standards Met:
TUV, FCC Class A, CE, RoHS/WEEE
