CP400 Dual-Channel, 400-Watt Commercial Power Amplifier
Please sign in so that we can notify you about a reply
A professional grade audio power amplifier specifically designed for demanding contractor applications, the CP400 features esoteric grade toroidal power supply and output transformers. These transformers were chosen for their outstanding reliability as well as extended frequency response (-3dB @ 30Hz - 16kHz via transformer output) Now you can have the peace of mind that systems specified with the CP400 will have true transformer output isolation, a feature that previously may have not been affordable due to the cost of quality external transformers.
CP400's two independent channels ensure maximum channel separation and ultra low distortion figures while providing years of faithful service.
Whether your application is a large distributed constant voltage sound system or a high SPL sound reinforcement system, the AtlasIED CP400 is the perfect answer for high power/low cost amplification needs.
Features
- 25V, 70.7V, 100V, and Direct Coupled (2,4, and 8 Ohm) Outputs Mounted on Barrier Strips with Covers for Safety
- Balanced Inputs on Barrier Strip and XLR Connectors
- Dual-Speed, High Efficiency Fan Cooling
- Loop Through Feature on Male XLRs, One per Channel Input
- Power-Up Muting
- Stepped Attenuators Mounted on the Rear for Security
- Toroidal Output Transformers Provide Full Electrical Isolation and Meet Worldwide Safety Agency Approval
- UL Listed - UL60065
Brand:
Atlas IED
Product Type:
Power Amplifier
Specifications
Number of Channels:
Special Features:
Soft Clip Limiter Protection, Dual-Speed, High Efficiency Fan Cooling
Power Rating:
876W
Applications:
Foreground Music System, Distributed Sound Masking, Night Club, Theatre, Portable Sound System
Indicator Type:
LED
Performance
Amplifier Class:
Class AB
Signal-to-Noise Ratio:
>100dB
Frequency Rating:
30Hz to 50kHz (Direct Output), 30Hz to 16kHz (Transformer Output)
Input Impedance Rating:
10kΩ (Balanced), 20kΩ (Unbalanced)
Input Sensitivity:
750mV (Balanced)
Dimensions
Width:
48.3cm
Depth:
42.8cm
Height:
13.2cm
