TSD-RL21 Two Channel Mixer
Please sign in so that we can notify you about a reply
The versatile AtlasIED TSD-RL21 2x1 mic/line mixer is ideal for applications where paging, public address, and BGM music is required. Use as a standalone remote mixer or in conjunction with AtlasIED power amplifiers in applications such as conference center meeting rooms, football stadiums, gymnasiums, retail/hospitality or other areas requiring versatile, multi-source mix control.Channel one may be configured via rear panel dipswitch to accommodate mic or line level while channel two features a stereo summing RCA line level input. Both inputs are adjustable by front panel controls with removable knobs, which may be easily replaced by security, covers to prevent tampering.The remote level control feature allows use of the AtlasIED AAVC-10K (or equivalent) decorative wall plate control for convenient remote adjustment of either the entire mix bus or RCA input 2 only (the typical BGM input).The TSD-RL21 is highly efficient and meets Energy Star standards as one 24V DC power supply (available separately) can power multiple Atlas Time Saving Devices.Unit requires Power Supply that is sold separately for proper function, multiple TSDs can be powered with one power supply based on current requirements. This unit has a power requirement of 60mA so any of the available TSD power supplies can be used with the unit. For multiple TSD applications use the TSD Power Calculator to determine the proper power supply needed.
Features- One (1) Mic/Line Input
- One (1) Summing RCA Line Input
- Remote Level Control Assignable Mix Bus or Input 2 Only
- Balanced Mono Line Out
- Input & Peak Signal Indicator LED'
- High Gain Output for Driving Long Balanced Lines
- Removable Phoenix Style I/O Connectors
- Security Covers Included for All Front Panel Controls
- Energy Efficient
- Power Supply Sold Separately
Brand:
Atlas IED
Product Type:
Two Channel Mixer
Specifications
Applications:
Church, Restaurant, Sports Bar, School, Industrial Facility, House of Worship
Performance
Maximum Frequency Rating:
20kHz
Signal-to-Noise Ratio:
85dBV (Line to Line), 70dBV (Mic to Line)
Minimum Frequency Response:
20Hz
Inputs and Ports
Connector Type:
Phoenix
Number of Ports:
1 (Mic/Line Input), 1 (Summing RCA Line Input)
Power
Current Rating:
60mA
Dimensions
Width:
10.1cm
Depth:
6.3cm
Height:
3.8cm
Weight:
0.1kg
Other
Voltage Rating:
24V DC
