CDB-6HR USB to Coaxial Audio Converter (up to 384kHz)
Please sign in so that we can notify you about a reply
This unit is a simple but smart device and no external power is required. It allows you to connect your PC/laptop to an audio amplifier or other audio destination that has an S/PDIF input without needing a dedicated audio card. This compact HD audio product supports LPCM 2.0 audio with a maximum sampling rate of 384kHz at 24bits. This unit connects to your PC/laptop using any available USB 2.0 (or higher) port (Windows and Mac OSX compatible).
Features
- Output HD audio from your PC/laptop to an audio amplifier
- Superior USB audio processor (XMOS U8A) which supports up to 384kHz/24bits sample rate
- Superior coaxial module supporting up to 384kHz audio
- Simple operation and compact design
- No external power required
Brand:
Cypress Technology
Product Type:
Audio Converter
Specifications
Maximum Operating Temperature:
+40°C
Output Audio Format Type:
LPCM 2
Converter Type:
USB to Coaxial Audio
Special Features:
Output HD Audio from your PC/laptop to an Audio Amplifier, Superior USB Audio Processor (XMOS U8A)
Applications:
High-Resolution Audio Playback, Improved Audio Quality from Laptops for Presentations or Entertainment
Material:
Aluminium
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
1xUSB to Coaxial Audio Converter, 1xDriver Disk, 1xOperation Manual
Performance
Bit Depths:
24bits
Sample Rate:
44.14888.296176.4192352.8384KHz
Inputs and Ports
Input Audio Format Type:
USB Audio 2.0
Number of Ports:
1 (Input), 1 (Output)
Dimensions
Width:
8.65cm
Depth:
2.5cm
Height:
2.2cm
Weight:
48g
No reviews found
