Extenders

• HDMI with HDR, 3D & 4K@60Hz support, Supports Deep Color input and output up to 12-bit
• Supports CEC bypass
• HDBaseT output transmits video, audio and data over a single Cat.5e/6/7 cable and can reach distances up to 70m/230ft at 4K when using Cat.6a/7
• Supported HDBaseT feature set: HD Video & Audio, 100BaseT Ethernet, PoH, and Control (Bi-directional IR/RS-232 pass-through)
• Integrated AVLC (Adaptive Visually Lossless Compression) activates when the bandwidth requirements of the source are beyond 10.2Gbps (340MHz) allowing for support of sources up to 18Gbps (600MHz) with no loss of visual quality
• The AVLC function allows manual selection between High Quality (Full bandwidth) mode and Standard mode (Lower bandwidth, activates at a lower bandwidth threshold)
• Supports pass-through of many audio formats including 8 channel LPCM, Bitstream, and HD Bitstream
• Receiver (PSE) provides power to the Transmitter (PD) using PoH (Power over HDBaseT)

Note:

The PoH function is designed for powering compatible Transmitter units only. Non-PoH Transmitters will need their own power supply. Transmitters from other brands may not be compatible.
