VP-425 Computer Graphics Video & HDTV to HDMI ProScale™ Digital Scaler
Please sign in so that we can notify you about a reply
The VP−425 is a high−performance digital scaler for computer graphics video and component HDTV signals. It up− or down−scales the input and embeds the stereo audio into the non−HDCP encrypted HDMI output.
Features
- HDTV Compatible.
- Max. Resolution — WUXGA & 1080p.
- Built–in ProcAmp — Color, sharpness, brightness, contrast, etc.
- Controls — Front panel with On–Screen Display (OSD).
- USB Port — For firmware upgrade.
- Compact MegaTOOLS™ — 2 units can be rack mounted side–by–side in a 1U rack space with the recommended rack adapter.
Brand:
Kramer
Part number:
70-42500090
Product Type:
HDMI Scaler
Specifications
Colour:
Black
Special Features:
Built-In Procamp-Color, Sharpness, Brightness, Contrast
Applications:
Projection Systems in Conference Rooms, Boardrooms, Hotels and Churches, Home Theatre Up-Scaling
Includes:
Power Supply
Performance
Resolution:
PC:VGA, SVGA, XGA, 1280x800, UXGA, SXGA, WXGA, SXGA+, WXGA+, WSXGA, WUXGA, HDTV: 480pixels, 576pixels, 720pixels@50Hz/60Hz, 1080pixels@50Hz/60Hz, 1080i@50Hz/60Hz
Signal Format:
HDMI
Inputs and Ports
Input Port Type:
1xVGA on a 15-Pin HD Connector, RGBHV/YPbPr (Selectable), 1xUnbalanced Stereo Audio on RCA Connector
Output Port Type:
1xDVI/HDMI on an HDMI Connector
Power
Current Rating:
400mA
Dimensions
Width:
18.75cm
Depth:
11.5cm
Height:
2.5cm
Weight:
0.4kg
Other
Voltage Rating:
5V DC
Voltage Rating:
5V DC
