CSC-6012RX 4K60 (4:4:4) 1x2 HDMI over HDBaseT Scaler with IR, RS-232, PoH (PD), LAN, OAR & Balanced Audio Extraction

Write a review
CSC-6012RX
Cypress Technology
Out of stock
Log in to see price Add to wish list

This HDBaseT to Dual HDMI Scaling Receiver can receive uncompressed audio/video along with control, Ethernet, and extra audio data over a single run of Cat.5e/6/7 cable up to 100m. While the HDBaseT input is limited to a maximum of 4K@60Hz (4:2:0, 8-bit), this unit can automatically convert or scale the input to output at 4K@60Hz (4:4:4, 8-bit) depending on the detected capability of the connected display. Simple 18Gbps HDMI test patterns are also available to be output for easy testing of local equipment. Control of remote devices is possible via bi-directional RS-232 or IR as well as via a LAN connection. Digital OAR (Optical Audio Return) support at 48kHz and a balanced analog audio output provides users with additional audio flexibility. The 48V PoH design can receive power from the connected Transmitter (PSE), eliminating the need for a local power supply, however power via 5V power supply is also supported if needed.

Features

  • Supports the HDBaseT 1.0 specification
  • HDBaseT 5Play™ convergence: High-Definition (HD) Video and Audio, 100BaseT Ethernet, 48V PoH, and Control (Bi-directional IR/ RS-232 pass-through)
  • Supports UHD resolutions up to 3840×2160@50/60Hz (YUV 4:4:4) & 4096×2160@50/60Hz (YUV 4:4:4) Supports pass-through of all standard digital audio: LPCM 2.0/5.1/7.1, Bitstream & HD Bitstream
  • Supports RS-232 baud rates from 110~115200bps
  • 10/100 Ethernet network support
  • Fully compliant with HDMI 1.4, and compatible with HDMI 2.0 (4K@60Hz, YUV 4:2:0)
  • HDMI with 18Gbps (600MHz) 4K support and HDCP 2.2 compliant
  • Supports Deep Color up to 1080p/12-bit
  • Supports DVI to HDMI conversion
  • Supports signal bypass on HDMI output (on the Transmitter)
  • Transmitter can upscale 1080p signals to 4K over HDBaseT output or downscale 4K signal to 1080p (same framerate is maintained)
  • Receiver supports signal bypass on both outputs or output B can upscale 1080p signals to 4K and output A can downscale a 4K signal to 1080p (same framerate is maintained)
  • Supports 4K UHD (4:4:4) to 4K UHD (4:2:0) conversion
  • Supports OAR (Optical Audio Return) and DAC balanced audio conversion
  • Test pattern generation at select resolutions for on-site display testing
  • Integrated EDID management
  • OSD with instant I/O resolution display
Brand:
Cypress Technology
Specifications
Product Type:
HDBaseT to HDMI Scaler
Maximum Operating Temperature:
+40°C
Silkscreen Color:
Black
Special Features:
Test Pattern Generation At Select Resolutions for On-Site Display Testing, Integrated EDID Management
IR Frequency:
30 to 50kHz
Power Rating:
20.28W
Chassis Material:
Metal
Applications:
Live Events Needing Dual Output Formats and Signal Extension, Hotel Ball Room with Extension and Audio Breakout, Long Distance Extension with No Local Power, On-Site Equipment Testing
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
Transmitter, 1xHDMI Over HDBaseT Scaling Transmitter, 1xIR Blaster Cable, 1xIR Extender Cable, 1xTerminal Block (3-Pin), 1xTerminal Block (5-Pin), 1xPower Cord, 1x24V/2.7A DC Power Adaptor, 1xOperation Manual, Receiver, 1xHDMI Over HDBaseT Scaling Receive
Performance
Resolution:
3840x2160pixels@50Hz/60Hz (YUV 4:4:4), 4096x2160pixels@50Hz/60Hz (YUV 4:4:4)
HDMI Compliance Type:
1.4
HDCP Compliance Type:
2.2
Video Bandwidth:
18Gbps (HDMI), 10.2Gbps (HDBaseT)
Signal Format:
HDMI
Baud Rate:
115200bps
Inputs and Ports
Input Port Type:
1xHDMI
Output Port Type:
1xHDMI, 1xCAT.5e/6/7, 1xBalanced Stereo Audio (5-Pin Terminal Block)
Power
Current Rating:
2.7A
ESD Protection Rating:
±12kV (Air-Gap Discharge), ±8kV (Contact Discharge)
Dimensions
Width:
21.35cm
Depth:
10.8cm
Height:
2.5cm
Weight:
670g
Other
Voltage Rating:
24V
Voltage Rating:
24V
Standards Met:
UL Listed, CE, FCC Complaint
