CP-259UHD UHD+ HDMI to HDMI Scaler
Please sign in so that we can notify you about a reply
This compact yet versatile HDMI to HDMI UHD Scaler accepts and outputs a wide range of resolutions up to 4K@60Hz (4:4:4, 8-bit) with simultaneous audio embedding and de-embedding of digital (HDMI or optical) or analog audio. Integrated EDID and HDCP management options allow for control over the way connected sources and displays detect the unit. The scaled HDMI output is powered by a high quality single-pass scaling engine with the ability to adjust the image with a number of fine tuning options including: contrast, brightness, hue, saturation, sharpness, noise reduction, and RGB levels. 3-D motion adaptive de-interlacing and frame rate conversion is supported as well.
Features
- Scaled HDMI output supports resolutions from 640×480@60Hz up to 4096×2160p@60Hz (4:4:4, 8-bit)
- Supports pass-through of many audio formats including LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream via HDMI
- Supports audio embedding and de-embedding via digital optical and analog stereo audio inputs and outputs (LPCM 2.0 only)
- Supports frame rate conversion, 3-D motion adaptive de-interlacing, and 3:2/2:2 pull-down detection and recovery
- Supports video adjustments to contrast, brightness, hue, saturation, sharpness, RGB levels and aspect ratio
- Integrated EDID and HDCP management
- Controllable via front panel buttons with comprehensive OSD
Brand:
Cypress Technology
Product Type:
HDMI to HDMI Scaler
Specifications
Maximum Operating Temperature:
+40°C
Silkscreen Color:
Black
Special Features:
Supports Video Adjustments to Contrast, Brightness, Hue, Saturation,Sharpness, RGB Levels and Aspect Ratio
Power Rating:
11W
Chassis Material:
Aluminium
Applications:
The Conversion of Multiple Video and Audio Formats to DVI
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
1xHDMI to HDMI Scaler, 1x5V/2.6A DC Power Adapter, 1xOperation Manual
Performance
Resolution:
HDMI:4096x2160pixels@60Hz (Input), HDMI:4096x2160pixels@60Hz (Output)
HDMI Compliance Type:
2.0 (DVI 1.0)
HDCP Compliance Type:
2.2, 1.x
Signal Format:
HDMI
Inputs and Ports
Input Port Type:
1xHDMI, 1xAnalog Stereo (3.5mm), 1xS/PDIF (TOSLINK)
Output Port Type:
1xHDMI, 1xAnalog Stereo (3.5mm), 1 S/PDIF (TOSLINK)
Power
Current Rating:
2.6A
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Width:
10.2cm
Depth:
14.7cm
Height:
2.5cm
Weight:
350g
Other
Voltage Rating:
5V
Voltage Rating:
5V
Standards Met:
UL Listed, CE, FCC Complaint
