CM-347 Video to PC/HD & DVI Scaler Boxes
Please sign in so that we can notify you about a reply
CM-347(ST)/CM-348(ST) are designed to convert Composite Video, S-Video ,YCbCr, and RGsB(CM-347/CM348) or RGBS(CM-347ST/CM-348ST), signals to a variety of computer and HDTV resolutions. It accepts video input of all video systems - NTSC, PAL and SECAM. CM-347/CM-348 series have many great features to upgrade video source to high resolution PC or HDTV quality and is ideal for use in professional large screen presentation. CM-348/CM-348ST have DVI digital output.
Features
- Video inputs are 3D de-interlaced and scaled up to PC or HDTV output resolution
- Automatically accommodates worldwide input video systems of NTSC 3.58, NTSC 4.43, PAL, PAL M, PAL N, and SECAM
- High performance adaptive digital 4H Comb filter Y/C separator with adjustable vertical peaking
- Motion compensated deinterlacing algorithms to produce artifact-free progressive scan video signal
- Built in adaptive film mode 3:2 / 2:2 pull-down provides clear and crisp de-interlacing of video originating from 24 fps film,such as DVD movies
- Frame rate up conversion from 50 up to 85Hz
- Vertical temporal filter(VT) removes jaggy and other de-interlacing artifacts from normal video
- OSD menu with adjustable control on Color,Sharpness,Brightness,Contrast and Tint(NTSC)
- Last memory for all adjustments
Brand:
Cypress Technology
Specifications
Product Type:
VGA & DVI Scaler
Colour:
Black
Special Features:
High Performance Adaptive Digital 4H Comb Filter Y/C Separator with Adjustable Vertical Peaking, motion Compensated Deinterlacing Algorithms to Produce Artifact-Free Progressive Scan Video Signal
Includes:
The Video to PC/HDTV Converter, Video RCA Cablex1, YPbPr RCAx3 to 8-Pin Din Cablex1, 15-Pin D-Sub PC to PC Cablex1, 15-Pin D-Sub to YPbPr 3-RCA Adaptor Cablex1, DVI Digital Cablex1, 5V 2A DC Power Adaptor, Centre Positive, User Manual, S Video Cablex1, 8-
Performance
Resolution:
HDTV:(480pixels@60Hz, 576pixels@50Hz Hz, 720pixels@50Hz/60 Hz), (1080i@50Hz /60 Hz, 1080pixels@50Hz/60 Hz) PC:(VGA@640x480), (SVGA@800x600, XGA@1024x768), WXGA@1360x768, WSXGA@1440x900), SXGA1280x1024, SXGA+@1400x1050, UXGA@1600x1200, WUXGA@19
Signal Format:
HDTV
Power
Current Rating:
2A
Dimensions
Width:
14.6cm
Depth:
7.7cm
Height:
3cm
Weight:
240g
Other
Voltage Rating:
5V
Voltage Rating:
5V
