CH-1507RX HDMI over CAT5e/6/7 Receiver with 48V PoH and LAN Serving
Please sign in so that we can notify you about a reply
Features
- HDMI With 3D, 4K×2K Support, HDCP and DVI Compliant
- Simultaneous Transmission Of Uncompressed Data Over a Single Cat5e/6/7 Cable Up to 100m/328ft
- HDbaset™ 5playt™ Convergence: Uncompressed High Definition Video and audio, Lan Serving, Power Over Ethernet and RS-232/Ir Control
- Uncompressed Video Support Up to 1080p @ 60 Hz/36-Bit
- High Definition audio Support Up to Lpcm 7.1ch, Dolby TrueHD,Dolby Digital Plus and Dts-HD Master audio
- Supports audio Sampling Rates Of 32 Khz to 192 Khz
- Supports Standard 48v Power From Transmitter (PSE) to Receiver (PD)
- Supports Cec Bypass
- Installation Friendly
Brand:
Cypress Technology
Product Type:
HDBaseT HDMI Receiver Over CAT5/6/7 with 48V PoE
Specifications
Maximum Operating Temperature:
+40°C
Special Features:
HDMI with 3D, 4Kx2K Support, HDCP and DVI Compliant, Simultaneous Transmission Of Uncompressed Data Over a Single Cat5e/6/7 Cable Up to 100m/328ft, Supports Audio Sampling Rates Of 32kHz to 192kHz
Power Rating:
15W
Chassis Material:
Aluminium
Applications:
Lecture Room Display and Control, Showroom Display and Control, Meeting Room Presentation and Control, Classroom Display and Control
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Storage Temperature Range:
-20 to +60°C
Performance
Maximum Input Resolution:
480i, 1080pixels@50Hz/60Hz, 1080pixels@24Hz, 3D
Inputs and Ports
Input Port Type:
1xHDMI, 1xIR Extender, 1xRS-232, 1xLAN
Output Port Type:
1xCAT5e/6/7, 1xIR Blaster
Power
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Width:
10.2cm
Depth:
11.3500/10.7cm (TX/RX)
Height:
2.5cm (TX/RX)
Weight:
262g (TX), 262g (RX)
Other
Standards Met:
CE, FCC Compliant, UL Listed
