CH-108 HDMI Dual CAT6 Repeater
Please sign in so that we can notify you about a reply
This is the Most advanced Solution for Cat6 to Cat6 Signal Repeater. these Two Cat6 Connectors are for Video and Ddc Ports of Transmitter and Receiver Which isolates the Ddc Capacitances of the Two Sides of the Buffer. This is Compatible With HDMI V1.3 Specifications, a Cutting-Edge Technology Which Defines the Supports to Transfer Deep Color (12 Bits/Color) Video and New Lossless Compressed (Dolby TrueHD, Dolby Digital Plus and Dts-HD Master audio) Digital audio.
Features
- HDMI 1.3, HDCP 1.1 and Dvi 1.1 Compliant
- Serial Data Rate at Up to 2.25Gbps, Capable Of Supporting the Following Digital Video formats In Deep Color Mode at Up to 36 Bits (12bits/color)
- DTV Resolutions: 480i, 576i, 480p, 576p, 720p, 1080i to 1080p
- Supports Cat-6 Cables for Data/Ddc Transmission
- Supports Equalize and Recover Incoming Tmds Data Before Re-Transmitting them With Optimal Quality Regardless Of the Incoming Signal Quality
- Supports High Definition Resolution, the Cable Distance Test With 1080p/8bits Resolution the Input/Output Source Can Run Up to 45/45 Meters
- Supports High Definition Resolution, the Cable Distance Test With 1080p/12bits Resolution the Input/Output Source Can Run Up to 15/15 Meters
- Supports Cec Bypass
- Supports Xvycc
Brand:
Cypress Technology
Product Type:
Dual CAT6 Repeater
Specifications
Maximum Operating Temperature:
+40°C
Colour:
Black
Special Features:
HDMI 1.3, HDCP 1.1 and DVI 1.1 Compliant, Serial Data Rate At Up to 2.25Gbps, Capable Of Supporting the Following Digital Video Formats in Deep Color Mode At Up to 36bits (12bits/colour), DTV Resolutions: 480i, 576i, 480pixels, 576pixels, 720pixels, 1080i
Chassis Material:
Aluminium
Minimum Operating Temperature:
0°C
Performance
HDMI Compliance Type:
1.3
HDCP Compliance Type:
1.1
Inputs and Ports
Input Port Type:
1xHDMI, 1xDDC
Output Port Type:
1xHDMI, 1xDDC
Dimensions
Width:
5cm
Depth:
7.2cm
Height:
2.3cm
Weight:
106g
