616R/T(SET)/EU 2-Fiber Detachable Dual Link DVI module - EU Version

Write a review
616R/T(SET)/EU
Kramer
Log in to see price Add to wish list Add to Project

The 614T and 614R are a small and lightweight, detachable optical transmitter and receiver pair. They transmit uncompressed DVI resolutions of up to 1920x1200 at 60Hz using one multimode fiber optic cable with SC connectors. The 614T converts the DVI signal to an optical signal that it transmits to the 614R. The 614R decodes the optical signals back to a DVI signal.

Features

  • Max. Data Rate — 4.95Gbps (1.65Gbps per graphic channel).
  • Max. Resolution — Up to WUXGA, 2K or 1080p (XGA not supported).
  • HDTV Compatible.
  • Not HDCP Compliant.
  • Standards Compliance — Certified for medical applications according to IEC 60601–1–2 (Electromagnetic Compatibility).
  • Laser Standards Compliance — IEC 60825–1, FDA 21CFR1040; Laser Class 1: Safety of laser products.
  • System Range — Up to 500m (1640ft) (multimode).
  • EDID Capture — Copies and stores the EDID from a display device (614T).
  • EMI/RFI Free.
  • Cable — 1 SC multimode fiber optic cable.
  • Power — External power adapters (supplied) or 5V DC from source (auto detect).
Brand:
Kramer
Part number:
50-00003190
Product Type:
Dual-Link DVI TX/RX Extender Over ultra-reach MM Fibre
Specifications
Maximum Operating Temperature:
+40°C
Version:
EU Version
Special Features:
Max. Data Rate, Max. Resolution, Not HDCP Compliant, Standards Compliance, Laser Standards Compliance-IEC 60825-1, FDA 21CFR1040, Laser Class 1: Safety of laser products, System Range-Up to 500m (1640ft) (multimode), EMI/RFI Free, EDID Capture, Cable-Dupl
Applications:
Digital Flat Panel and Plasma Displays, for Medical, Commercial and Travel, Conference Rooms and Auditoriums, Kiosks with Digital Flat Panel Displays for Presenting Information, Led Signboards in Streets and Stadium
Humidity:
10 to 85%
Minimum Operating Temperature:
0°C
Includes:
Two 5V DC/1A Power Supply
Storage Temperature Range:
-40 to +70°C
Performance
Maximum Output Resolution:
13.5Gbps (2.25Gbps bandwidth per graphic channel), WQUXGA@33Hz (XGA is not supported)
Inputs and Ports
Input Port Type:
1xDVI (616T), 1 Duplex MultiMode Fibre Optic with 2 LC Connector (616R)
Output Port Type:
1 Duplex Multimode Fibre Optic with 2 Lc Connectors (616T), DVI Out (616R)
Dimensions
Width:
3.9cm
Depth:
7.2cm
Height:
1.5cm
Weight:
0.14kg
Other
Standards Met:
IEC 60825-1, FDA 21CFR1040

616R/T(SET)/EU 2 (616R.pdf, 131 Kb) [Download]
