iTrans E150CL-T HDMI over HDBaseT Transmitter, for iMatrix MI2K-HBT150 input card
Please sign in so that we can notify you about a reply
The HDMI Extender with Loopout can extend HDMI signal over 500 feet/150 meters to an HDMI compatible display via single Cat5e/6 cable. It also supports bi-directional Infrared control signal and RS-232 transmission together with HDMI signal, it allows you to easily control your DVD player at TV side or control your TV at the DVD player side when using this extender.
Features- HDMI 1.4, HDCP 1.4 and DVI compliant
- Video resolutions up to 1080p@60Hz (YUV4:4:4)
- HDMI High Bit Rate(HBR) audio pass through
- 150 meters transmission distance over CAT6 cable
- POC (Power over Cable), either TX or RX is powered by one 24V@1A power supply
Brand:
Infobit
Product Type:
HDBaseT Transmitter
Specifications
Maximum Operating Temperature:
+40°C
Transmission Range:
150m
Special Features:
Bi-Directional RS-232 Signal Transmission
Power Rating:
6W
Chassis Material:
Metal
Humidity:
20 to 90%
Chassis Colour:
Black
Minimum Operating Temperature:
0°C
Performance
Video Format:
1080P@60Hz
Frequency Rating:
50/60Hz
Inputs and Ports
Input Port Type:
1×HDMI, 1xIR
Output Port Type:
1xHDBaseT, 1xHDMI, 1xIR
Interface Type:
RS232, RJ45
Power
Current Rating:
1A
Dimensions
Width:
14cm
Depth:
6.5cm
Height:
1.8cm
Weight:
240g
Other
Voltage Rating:
100 to 240V AC (Input), 12V DC (Output)
Standards Met:
US/EU Standards, CE/FCC/UL Certified, RoHs Complaint
Warranty:
3 year
