PT-120XL Computer Graphics Video over Twisted Pair Receiver
Please sign in so that we can notify you about a reply
The PT-120xl is an extended range twisted pair receiver for computer graphics video signals. It converts a twisted pair signal from a WP-110 transmitter (or other compatible Kramer transmitter) to a computer graphics signal.
Features
- HDTV Compatible.
- Max. Resolution — WUXGA & 1080p.
- Level (Gain) & EQ (Peaking) Controls.
- System Range — Up to 250m (820ft). Greater distances possible depending on signal resolution and cable.
- Cable — UTP (unshielded twisted pair) or STP (shielded twisted pair) cable such as CAT 5.
- Power Connect™ System — A single connection to the transmitter or the receiver powers both units when the devices are within 150ft (50m) of each other.
Brand:
Kramer
Part number:
50-80249090
Product Type:
Computer Graphics Video Over Twisted Pair Transmitter
Specifications
Maximum Operating Temperature:
+40°C
Special Features:
Level (Gain) and EQ (Peaking) Control, System Range-Up to 250m (820ft). Greater Distance Possible Depending on Signal Resolution and Cable, Cable-UTP (Unshielded Twisted Pair) or STP (Shielded Twisted Pair) Cable Such as CAT 5, Power Connect™ System-a S
Applications:
Presentation and Multimedia, Schools, Hospitals, Security
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Includes:
Power Supply 5V, 2xHDMI Cables 0.9m (2.95ft) PN 2518-0101003, 1xIR Emitter Cable PN 3300-500135
Performance
HDMI Compliance Type:
1.0
Signal-to-Noise Ratio:
70dB
Maximum Resolution:
Up to WUxGA, 1080pixels
Inputs and Ports
Input Port Type:
1xRJ45 Connector
Output Port Type:
1xVGA/UxGA on a 15-Pin HD Connector
Power
Current Rating:
350mA
Dimensions
Width:
6.22cm
Depth:
5.1cm
Height:
2.4cm
Weight:
0.1kg
Other
Voltage Rating:
12V DC
Voltage Rating:
12V DC
