CH-730TX Cable Transmitter, 1×USB 3.2 Type-C, 1×USB 3.2 Type-A, Black
Please sign in so that we can notify you about a reply
This USB 3.2 Gen1 extender set is designed to extend signal from one USB host to multiple USB devices for up to 100 meters (328 feet) when paired with receiver from the homologous series. This transmitter enables the extension from the USB-C host to a local USB device and USB devices on the receiver. The transmitter can be powered by a connected host device such as a computer or laptop, without the need for an external power adaptor. Type-A port can provide up to 5V/900mA (4.5W) power when unit is active. The unit also has a hotkey for convenient firmware update.
Features- Support USB 3.2 Gen1 with 1 USB-C host port and 1 USB-A device port
- Support Point-to-Point transmission
- Transmission up to 100 meters (328 feet)
- The transmitter can be powered by a connected host such as a computer or laptop
- The host can control multiple USB devices on transmitter side and receiver side
- Firmware update with hotkey from the transmitter, enabling remote firmware updates to the receiver.
- Backward compatible with USB 2.0
Brand:
Cypress Technology
Product Type:
Transmitter
Specifications
Maximum Operating Temperature:
40°C
Transmission Range:
100m
Special Features:
Extend Signal from One USB Host to Multiple USB Devices for up to 100m, Compatible with USB 2.0
Power Rating:
8.34W
Chassis Material:
Aluminium
Applications:
Remote USB Extension, Security and Monitoring, Industrial Control, Conference Room and Boardroom KVM Extension
Humidity:
20 - 90% RH (Non-Condensing)
Chassis Colour:
Black
Minimum Operating Temperature:
0°C
Includes:
1×USB 3.2 over Category Cable Transmitter, 1×Operation Manual
Inputs and Ports
Input Port Type:
1×USB 3.2 Type-C
Output Port Type:
1×USB 3.2 Type-A
Interface Type:
1×USB-C (Input), 1×USB A (Output)
Power
Current Rating:
1.25A
Dimensions
Width:
10.3cm
Depth:
6cm
Height:
2.4cm
Weight:
1kg
Other
Voltage Rating:
12V DC
Standards Met:
US, EU, CE, FCC, UL
