CH-527RXPLVBD 4K UHD+ HDMI over HDBaseT Receiver with Bidirectional 24V PoC

Write a review
CH-527RXPLVBD
Cypress Technology
Out of stock
Log in to see price Add to wish list

This HDMI over HDBaseT Receiver is a great solution for extending UHD video and audio as well as Ethernet and control via a single run of Cat.5e/6/7 cable over distances up to 70 meters. This extender complies with the advanced HDCP 2.2 and HDMI 2.0 standards, as well as supporting the legacy HDCP 1.x and HDMI 1.x standards. In addition, despite HDBaseT’s 10.2Gbps bandwidth limitation, 4K UHD HDMI video sources, up to and including 4K@60Hz (4:4:4, 8-bit) as well as 10/12-bit sources with HDR, are able to be processed and extended by the use of AVLC (Adaptive Visually Lossless Compression) when needed. Multiple data and control interfaces are also able to be extended, including IR, RS-232, and LAN connections. This unit supports bi-directional 24V PoC (Power over Cable) allowing the system to be completely powered by, or provide power to, a compatible connected Transmitter, allowing for greater flexibility within different installation scenarios.

Features

  • HDMI with HDR, 3D & 4K@60Hz support, DVI 1.0 compatible
  • HDCP 1.x and HDCP 2.2 compliant
  • Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input and output
  • Supports Deep Color input and output up to 12-bit
  • Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output
  • Supports CEC bypass
  • HDBaseT feature support: HD Video and Audio, 24V PoC and Control (bi-directional IR/RS-232 pass-through)
  • HDBaseT input receives video, audio and data over a single Cat.5e/6/7 cable and can reach distances up to 70m/230ft at 1080p and 40m/131ft at 4K when using Cat.6a/7
  • Integrated AVLC (Adaptive Visually Lossless Compression) activates when the bandwidth requirements of the source are beyond 10.2Gbps (340MHz) allowing for support of sources up to 18Gbps (600MHz) with no loss of visual quality
  • Supports pass-through of many audio formats including LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream
  • Bi-directional 24V PoC allows the unit to be powered by, or provide power to, a compatible connected Transmitter
Brand:
Cypress Technology
Specifications
Product Type:
K UHD+ HDMI Over HDBaseT Receiver
Maximum Operating Temperature:
+40°C
Number of Channels:
Special Features:
HDMI with HDR, 3D and 4K@60Hz Support, DVI 1.0 Compatible, Supports Deep Color Input and Output Up to 12bits, Supports 10bits and 12bits HDR (High Dynamic Range) Input/Output, Supports CEC Bypass, Supports Pass-Through of Many Audio Formats Including LPCM
IR Frequency:
30 to 50kHz
Applications:
Household Entertainment Sharing and Control, Lecture Room Display and Control, Showroom Display and Control, Meeting Room Presentation and Control, Classroom Display and Control
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Performance
HDMI Compliance Type:
2.0
HDCP Compliance Type:
1.x, 2.2
Video Bandwidth:
10.2Gbps
Baud Rate:
Up to 115200bps
Inputs and Ports
Input Port Type:
1xHDBaseT (RJ45)
Output Port Type:
1xHDMI
I/O Interface Type:
IR/RS-232
Power
Current Rating:
1.25A
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Width:
10.2cm
Depth:
10.7cm
Height:
2.5cm
Weight:
260g
Other
Voltage Rating:
24V DC
Voltage Rating:
24V DC
Standards Met:
US, EU Standards, CE, FCC Compliance, UL Listed
