SWT3-31-HU Full Featured USB-C & HDMI 3x1 Switcher

Write a review
SWT3-31-HU
Kramer
Log in to see price Add to wish list

SWT3-31-HU is a high-performance auto-switcher with one USB-C and two HDMI/USB inputs and HDMI output. The connected USB peripherals, such as a room camera and microphone, are switchable for use of the active USB host, for convenient hybrid meeting operation with both room and online participants.

Features
  • Hybrid-meeting Collaborative Switching
  • BYOD Ease and Convenience
  • HDMI Signal Switching
  • USB 3.1 Switching
  • HDMI Mirroring
  • I–EDIDPro™ Kramer Intelligent EDID Processing™
  • Audio De–embedding
  • Auto Switcher Ease of Use
  • Display On/Off Operation
  • Simple Control
  • Built–in Intelligent Control Gateway
  • Secured Network Connection
  • Comprehensive Management
  • Easy and Elegant Installation
  • Convenient Display Power On/Off Control
  • Easy Online Meeting System Integrated Connectivity
Brand:
Kramer
Part number:
50-80583090
Specifications
Product Type:
USB–C/HDMI Switcher
Maximum Operating Temperature:
+40°C
Rack Form Factor:
1U
Switching System:
Automatic
Special Features:
Hybrid-Meeting Collaborative Switching, BYOD, Audio De-Embedding, Built–in Intelligent Control Gateway, Comprehensive Management
Power Rating:
84W (Source), 7.8W (PoE), 60W (USB Host Charging)
Applications:
Enterprise and Education Hybrid Huddle Spaces, Hybrid User Connection Element in Advanced Hybrid Meeting Solution
Material:
Aluminium (Enclosure)
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Includes:
Power Adapter
Performance
Impedance Rating:
500Ω
Maximum Output Resolution:
4Kpixels@60Hz (4:4:4)
Signal-to-Noise Ratio:
85dB
Signal Level:
14.5dBu
Frequency Rating:
60Hz
Inputs and Ports
Output Type:
1xHDMI: On HDMI Female Connector, 1xHDMI Loop: On HDMI Female Connector, 1xBalanced Stereo Audio Line: On 5-pin Terminal Block Connector, 1xIR: On a 3.5mm Mini Jack for IR Extension
Port Type:
1xEthernet: On RJ-45 Female Connector (LAN Connection), 1xUSB 3.1 Host: On a USB-C Female Connector, 2xUSB 3.1 Host: On a USB-B Female Connector, 4xUSB 3.1 Device: On USB-A Female Connector
Input Type:
1xDP Alt Mode & PD 3.0 USB-C: On a USB-C Female Connector, 2 HDMI: On HDMI Female Connector
Number of Ports:
3
Power
Current Rating:
6A (Source), 4.4A (Consumption), 144mA (PoE), 2A (USB Device Charging)
Power Connector Type:
1xRS232: On a 3-pin Terminal Block, 2xGPIO: On a 2-pin Terminal Block
Dimensions
Width:
19cm
Depth:
11.6cm
Height:
2.7cm
Weight:
0.6kg
Shipping Weight:
1.2kg
Other
Voltage Rating:
20V DC
Standards Met:
CE, UL, RoHs, WEEE

SWT3-31-HU 1 (SWT3-31-HU, 847 Kb) [Download]
