CSC-8000 Matrix Presentation Switcher, 6x2 +UHD

Write a review
CSC-8000
Cypress Technology
Log in to see price Add to wish list Add to Project

This 6 by 2 Matrix is a multi-format switcher with integrated scaling featuring HDMI, DisplayPort, USB Type-C, and HDBaseT. The HDMI, DisplayPort and USB-C ports support resolutions up to 4K@60 (4:4:4, 8-bit) while the HDBaseT output supports automatic down-conversion of 4K60(4:4:4) sources to 4K60(4:2:0). This unit can send high definition uncompressed audio/video along with Ethernet, USB, IR, and RS-232 over a single Cat.6A cable up to a distance of 100 meters as well as providing 48V PoH power to compatible HDBaseT Transmitters and Receivers. This unit also includes multiple analog stereo audio inputs and a microphone inputs along with an amplified analog stereo output to provide a range of audio routing and mixing flexibility. The built-in audio mixer function allows the user to mix audio from any analog input with the microphone input for presentation or lecture usage. The ability to switch back and forth between mixed and non-mixed audio greatly simplifies the presentation experience. Standard control is available via front panel buttons with an On-Screen Display (OSD), WebGUI, Telnet, and RS-232 making it exceptionally versatile.

Features
  • HDMI 2.0, DisplayPort 1.4 compliant
  • HDCP 1.x and 2.2 compliant
  • 6 video inputs (1×USB-C, 1×HDBaseT, 3×HDMI, 1×DisplayPort) and 2
  • Outputs(HDMI & HDBaseT)
  • Independent audio routing from any audio inputs to outputs
  • Supported HDBaseT feature set: HD Video & Audio, 48V PoH, and Control
  • (Bidirection IR/RS-232 pass through)
  • Supports manual input selection or automatic input selection for video
  • And usb, with hot plug detection and “Last Memory" feature
  • Comprehensive EDID and HDCP management
  • Audio mixer function allows the mixing of audio from any 4 LPCM 2.0
  • Audio sources, including the microphone inputs(5 mixers in total)
  • USB Type-C port provides up to 60W to power or charge the connected
  • Device when the switcher charge locally
  • Trigger Control Keypad support for easy, single-button and function
  • Activation (Optional)
  • Supports standard PoH (PSE) from the HDBaseT output and HDBaseT
  • Inputs to connected HDBaseT (PD) transmitters and receiver (compatible
  • Transmitters/receivers only)
  • Controllable via front panel controls with OSD, RS-232, Telnet, WebGUI,
  • And triggers
Brand:
Cypress Technology
Product Type:
Presentation Switcher
Specifications
Colour:
Black
Control Port Type:
1xRS-232 (3-pin Terminal Block), 1×Trigger (10-pin Terminal Block), 2xUSB (Type-B), 2xUSB (Type-A), 1xLAN (RJ-45)
Special Features:
Independent Audio Routing, Audio Mixer Function, Trigger Control Keypad, Controllable via Front Panel Control
IR Frequency:
20Hz to 20kHz
Power Rating:
40W
Chassis Material:
Steel
Includes:
Multiple Analog Stereo Output, Microphone
Performance
Resolution:
4096x2160pixel@60 (YUV 4:4:4)
Signal-to-Noise Ratio:
>104dB
Total Harmonic Distortion:
<-80dB@0dBFS
Crosstalk Level:
<-80dB, <-70dB
Inputs and Ports
Input Port Type:
3xHDMI Type-A, 1xDisplayPort, 1xUSB Type-C, 1xHDBaseT (RJ-45), 1xStereo Audio (3.5mm), 1xStereo Audio (5-pin Terminal Block), 2xMicrophone (5-pin Terminal Block)
Output Port Type:
1xHDBaseT (RJ-45), 1xHDMI (Type-A), 1xStereo Audio Class D amplifier (2x2-pin Terminal Block), 2xBalanced Analog Stereo (5-pin Terminal Block)
Number of Ports:
27
Power
Current Rating:
6.25A
Dimensions
Length:
4.3cm
Width:
4.4cm
Height:
2.6cm
Other
Voltage Rating:
24V
