CPLUS-V4H1HP UHD 4 to 1 Switcher
Please sign in so that we can notify you about a reply
This 4×1 HDMI switcher is the most advanced HDMI solution for true Ultra High-Definition signal routing. This unit allows for the switching of any of four 18Gbps HDMI input signals to a single 18Gbps HDMI display device. Resolutions up to 4096×2160@60Hz (4:4:4), 16-bit Deep Color, HDR (High Dynamic Range), HD audio as well as other features defined by the HDMI 2.0 specification are supported. Multiple control interfaces are available including RS-232, Ethernet (WebGUI & Telnet), IR remote and front-panel buttons making operation easy and intuitive.
Features
- Supports data rates up to 18Gbps and Deep Color (16-bit) up to 1080p
- Supports pass-through of LPCM 7.1, Bitstream and HD Bitstream audio formats
- Remotely controllable via Ethernet (WebGUI & Telnet), RS-232 and IR remote
Brand:
Cypress Technology
Product Type:
HDMI Switcher
Specifications
Display Type:
PC, TV
Audio Format:
LPCM
Maximum Operating Temperature:
+40°C
Colour:
Black
RS-232 Connector Type:
DB-9
Power Rating:
5.83W
Applications:
Entertainment Rooms and Home Theatres, Showrooms and Demo Rooms, Lecture Room, Hall Presentations, Public Commercial Display
Material:
Metal
Humidity:
20 to 90% RH (Non-Condensing)
Minimum Operating Temperature:
0°C
Includes:
4 by 1xHDMI Switcher, Remote Control (CR-72), IR Extender Cable, 5V/2.6A DC Power Adaptor, Operation Manual
Performance
Bandwidth:
18Gbps
Video Processing:
4:4:4, 16bits
Audio Sample Rate:
8bits, 60Hz
Maximum Resolution:
4096x2160pixels
Inputs and Ports
Video Input Type:
HDMI-Type A
Power
Current Rating:
2.6A
Dimensions
Width:
24cm
Depth:
11.2cm
Height:
4.8cm
Weight:
850g
Other
Voltage Rating:
5V DC
Voltage Rating:
5V DC
Standards Met:
US/EU Standard, CE, FCC Compliant, UL Listed
