CPLUS-V4H1H 4x1 UHD+ Switcher
Please sign in so that we can notify you about a reply
This 4 by 1 HDMI Switcher is a brand new high performance design for the next generation of audio/video equipment. It allows a single HDMI output to switch between 4 HDMI sources. This unit comes with full support for 18Gbps (600Mhz) resolutions up to, and including 4K@60Hz (4:4:4, 8-bit) as well as support for 16-bit Deep Color up to 1080p60Hz, HDR (High Dynamic Range), HD audio and other features defined by the HDMI 2.0 specification. The included auto switching functionality allows for the possibility of hands-free, user friendly, operation. Control is provided via front panel buttons, IR remote, and RS-232.
Features
- Supports pass-through of audio formats including LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream
- CEC pass-through
- Support Internal/External EDID management
- Controllable via front-panel buttons, RS- 232, and optional IR remote
Brand:
Cypress Technology
Product Type:
HDMI Switcher
Specifications
Display Type:
PC, TV
Audio Format:
LPCM
Maximum Operating Temperature:
+40°C
Colour:
Black
RS-232 Connector Type:
DB-9
Power Rating:
6.6W
Applications:
Demo Room Display, Hotel Lobby Information Displays, Showrooms and Demo Rooms, Public Commercial Display, Home Theatre
Material:
Metal
Humidity:
20 to 90% RH (Non-Condensing)
Minimum Operating Temperature:
0°C
Includes:
4 by 1xHDMI Switcher, 5V/2.6A DC Power Adapter, 3.5mm to IR Extender Cable [Optional], Remote Control (CR-72) [Optional], Shockproof Feet (Set of 4), Operation Manual
Performance
Bandwidth:
18Gbps
Video Processing:
4:4:4, 8bits
Audio Sample Rate:
8bits, 60Hz
Maximum Resolution:
4096x2160pixels
Inputs and Ports
Video Input Type:
HDMI-Type A
Power
Current Rating:
2.6A
Dimensions
Width:
21.35cm
Depth:
11.7cm
Height:
2.5cm
Weight:
608g
Other
Voltage Rating:
5V DC
Voltage Rating:
5V DC
Standards Met:
US/EU Standard, CE, FCC Compliant, UL Listed
