CPLUS-V3H1H-TB UHD+ 3x1 HDMI Switcher Table Box

This UHD+ 3×1 HDMI Switcher Table Box features three HDMI inputs and one HDMI output with manual or automatic source switching. Every input and output supports full bandwidth 4K@60Hz (4:4:4, 8-bit) HDMI 2.0 with HDCP 2.2 signals. Automatic source management allows for hands-free switching based on input signal and hot plug detection with a “Last Memory” switching feature upon signal loss. This switch is an ideal addition to any conference room, lecture hall or home entertainment setup with its portable and easy to install design. The table box is designed to be placed on a table, or mounted to any typical table edge using a clamp. Control is via a front panel button and RS-232.

Features

  • Supports Deep Color input and output up to 12-bit
  • Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output
  • Supports pass-through of many audio formats including 8 channel LPCM, Bitstream, and HD Bitstream
  • Supports manual input selection or automatic input selection with hot plug detection and “Last
  • Memory” feature
  • Sophisticated EDID management ensures optimal compatibility
  • LED indicators provide input selection as well as automatic switch status information
  • Convenient table box design
  • Control via front panel button and RS-232
Brand:
Cypress Technology
Product Type:
HDMI Switcher
Specifications
Display Type:
PC, TV
Audio Format:
LPCM
Maximum Operating Temperature:
+40°C
Colour:
Black
Power Rating:
2.53W
Applications:
Conference Rooms and Boardrooms, Lecture Halls, Auditoriums, Classroom, Household Entertainment Sharing and Control, Hotel Event Space
Material:
Aluminium
Humidity:
20 to 90% RH (Non-Condensing)
Minimum Operating Temperature:
0°C
Includes:
UHD+ 3x1xHDMI Switcher Table Box, 5V/1A DC Power Adapter (2-Pin Terminal Block),, Operation Manual
Performance
Bandwidth:
18Gbps
Video Processing:
4:4:4, 8bits
Audio Sample Rate:
8bits, 60Hz
Maximum Resolution:
4096x2160pixels
Inputs and Ports
Video Input Type:
3xHDMI (Type A)
USB Type:
USB 2.0 (Mini B)
Power
Current Rating:
1A
Dimensions
Width:
12.5cm
Depth:
4cm
Height:
5.5cm
Weight:
230g
Other
Voltage Rating:
5V DC
Voltage Rating:
5V DC
Standards Met:
US/EU Standard, CE, FCC Compliant, UL Listed
