VS-88HDxl/220V 8x8 3G HD-SDI Matrix Switcher, 220V
Please sign in so that we can notify you about a reply
The VS−88HDxl is a high−performance matrix switcher for 3G HD−SDI and HD−SDI dual link video signals. The unit can switch any or all inputs to any or all outputs. Switching is implemented during the vertical interval period according to the SMPTE RP−168 standard, when using synchronized digital video sources.
Features
- Max. Data Rate - 3Gbps.
- Multi-Standard Operation SDI (SMPTE 259M & SMPTE 344M), HD-SDI (SMPTE 292M), 3G HD-SDI (SMPTE 424M) and dual link HD-SDI (SMPTE 372M).
- Automatic Equalization Technology.
- Looping Analog Sync Input.
- Selectable Sync Signal Termination.
- Analog Sync Type - Bi-level, tri-level.
- Take Button - Executes multiple switches all at once.
- Multiple Memory Locations - Stores multiple switches as presets (salvos) to be recalled and executed when needed.
- Vertical Interval Switching - Synchronizes either to external reference or the incoming video in compliance with SMPTE RP-168.
- Flexible Control Options - Front panel, RS-232 (K-Router Plus™ Windows®-based software is included), RS-485, Ethernet, contact closure & IR remote (available upon request).
- Front Panel Control Lockout.
- Worldwide Power Supply - 100-240V AC.
- Standard 19” Rack Mount Size - 1U. Rack “ears” included.
Brand:
Kramer
Part number:
21-70723020
Specifications
Product Type:
Matrix Switcher
Colour:
Black
Control Port Type:
Front Panel, RS-232, RS-485, Ethernet, Remote Infrared
Version:
220V
Special Features:
Automatic Equalization Technology, Front Panel Control Lockout
Power Rating:
24VA
Applications:
Professional Broadcasting and Production Studios, Presentation
Includes:
Power Cord
Performance
Video Bandwidth:
3Gbps
Inputs and Ports
Input Port Type:
8xSMPTE-259M, 344M, 292M, 372M, 424M Serial Video, 75Ω on BNC Connector
Output Port Type:
8xEqualized and Reclocked SMPTE-259M, 344M, 292M, 424M, 372M (Dual Link) Output 75Ω on BNC Connector
Number of Ports:
8x8
Dimensions
Length:
23.7cm
Width:
43.6cm
Height:
4.3cm
Weight:
1.9kg
Other
Voltage Rating:
100 TO 240V AC
