iMatrix H88HAW Matrix Switcher, 8x8 4K60 HDMI, Seamless UHD
Please sign in so that we can notify you about a reply
The 18Gbps 4x4 seamless UHD Matrix can connect 4 HDMI sources to 4 HDMI displays. Supported video resolution is up to 4K60 4:4:4. The product supports IR matrix and Audio matrix. IR matrix routing follows the video routing. Audio extract and insert are supported. The product supports CEC management and strong video wall processing.
Features- IMatrix H88HAW
- 8x8 18Gbps HDMI 4K60 Seamless Matrix Switcher with Videowall
- HDMI 2.0 and HDCP 2.2 compliant
- Support 18 Gbps video bandwidth
- Support seamless switching
- Support video wall
- Support IR matrix
- Support HDMI audio extract
- Support external L/R audio insert on HDMI stream
- Support EDID management
- HDMI video output resolution up to 3840x2160@60
- Support front panel, RS232, TCP/IP (LAN 10M/100M) control
Brand:
Infobit
Product Type:
Matrix Switcher
Specifications
Maximum Operating Temperature:
40°C
Colour:
Black
Control Port Type:
8xIR IN (3.5mm Stereo Mini-Jack), 8xIR OUT (3.5mm Stereo Mini-Jack), 1xTCP/IP (RJ45), 1xRS-232 (D-Sub 9)
Special Features:
Support Seamless Switching, Video Wall Function
Power Rating:
100W
Applications:
Broadcast, Education, Conference, Home Theater, Control Room and Digital Signage
Humidity:
10 to 50%
Minimum Operating Temperature:
0°C
Includes:
1x4K60 8x8 Seamless UHD Matrix, 1xAC Power Cord, 1xMatrix IR Remote, 4xIR Receiver cable (1.5 m), 4xIR Blaster cable (1.5 m), 1x3-pin Phoenix Connector, 1×CAT6 Cable, 1×USB to RS232 Cable, 1×User Manual
Performance
Resolution:
4K60Hz (4:4:4)
Video Bandwidth:
18Gbps
Baud Rate:
9600bps
Inputs and Ports
Input Port Type:
8 xHDMI Type A, 8xCoaxial Audio (3.5mm Stereo Mini-Jack)
Output Port Type:
8xHDMI Type A, 8xCoaxial Audio (3.5mm Stereo Mini-Jack)
Number of Ports:
16
Power
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Length:
43cm
Width:
30cm
Height:
4.4cm
Weight:
5kg
Other
Voltage Rating:
100 to 240V DC
