iMatrix H44AM Matrix Switcher, 4x4, 4K60 HDMI with Audio Matrix/Downscaler
Please sign in so that we can notify you about a reply
The H44AM is a professional 4x4 HDMI 2.0 Matrix Switcher with Audio Matrix. It includes 4 HDMI inputs, 4 HDMI outputs and the last two outputs with down-scaling function, which is designed for switching two HDMI2.0 and HDCP2.3 compliant signals. It also features 4 SPDIF and 4 analog audio outputs for audio matrix.
Features- HDMI 2.0b and HDCP 2.2 compliant
- HDMI 18Gbps video bandwidth, up to 4K60 YCbCr 4:4:4 24bit
- Pure-hardware and modular design, 4 ports per card
- Support 8x8/16x16/36x36 inputs and outputs
- Input and output supports HDMI, DVI-U (DVI/VGA/YPbPr/CVBS), VGA, 3G/HD/SD-SDI, HDBaseT and optical fiber
- Resolutions: 1920×1200p60hz (2K card), 3840x2160p60hz (4K card)
- Seamless switching without image tear, black-screen or flicker
- Gen-Lock videowall technology, the latency between any output channel is less than 0.1ms
- Any videowall layout modes in the allowed range of 8x8-36x36, especially suitable for LCD/LED video wall
- Built-in HDCP processing technology
- Input cards support audio-embedding, output cards support audio de-embedding
- Up to 64xof scene-presets can be recalled
- Advanced EDID management
- Control via front panel buttons, IR, RS-232, TCP/IP, Web GUI or PC software
- Silent fan design, noiseless, stable performance
- Redundant dual-power design
Brand:
Infobit
Product Type:
Matrix Switcher
Specifications
Maximum Operating Temperature:
55°C
Colour:
Black
Control Port Type:
1xIR Eye, 1xRS232, 1xFirmware, 1xTCP/IP
Special Features:
Audio Matrix, Audio Out Can Be De-Embedded From Arbitrary Input or Output
IR Frequency:
20Hz to 20kHz
Power Rating:
18.3W
Applications:
Broadcast, Education, Conference, Home Theater, Control Room, Digital Signage
Humidity:
10 to 90%
Minimum Operating Temperature:
-5°C
Includes:
1xH44AM , 1xRS232 Cable (3-pin to DB9), 1xIR Remote, 1xUser Manual, 2xMounting Ears with 6 Screws, 4xPlastic Cushions, 1xIR Receiver, 1xPower Adapter
Performance
Resolution:
Up to 4K@60Hz (4:4:4)
Video Bandwidth:
18Gbps
Signal-to-Noise Ratio:
>90dB
Crosstalk Level:
-70dB
Inputs and Ports
Input Port Type:
4xHDMI Type-A Female
Output Port Type:
4xHDMI Type-A Female
Number of Ports:
8
Power
Current Rating:
1.25A
Dimensions
Length:
43.6cm
Width:
4.4cm
Height:
23.6cm
Weight:
2.6kg
Other
Voltage Rating:
24V DC (Output), 100 to 260V AC (Input)
