CPLUS-V4H2HP-DTDA UHD+ 4x2 HDMI Matrix with Dante and Dolby Digital & DTS Stereo Audio Decoder
Please sign in so that we can notify you about a reply
Dante® (digital audio network through Ethernet) is a powerful technology that allows many audio channels to be sent and received through Ethernet. CPLUSV4H2HP-DTDA integrates Dante® technology, 4×2 MATRIX and DSP audio processor allows the user to route four 18Gbps HDMI input signals to any of two 18Gbps HDMI and Dante® digital audio outputs. Dante digital audio output enables audio transport of up to two stereo audio signals over a network using standard Internet protocols. It also supports AES67 and Audinate Dante® Controller. Ethernet is used for remote control while a front panel with buttons optimized for use in challenging environments, allows full local control of all features. The DSP processing technology are with new adaptive feedback and noise cancellation functions. The integration of Dante® audio out facilitates system expansion when paired with many of Cypress’s Dante-enabled audio processing products.
Features
- Enabled HDMI de-embedded/embedded designed to bridge 2-channel PCM HDMI audio to/from a Dante audio network
- Balance Audio out can be switch between HDMI De-embedded audio or Dante® -In source
- Dante audio networking utilizes standard IP networks to transmit high-quality, uncompressed audio with near-zero latency
- Non-compress audio performance
- Audio output supports 48kHz Sampling Rate
- Supports Dante / AES67 inputs and outputs
- Sample-accurate time alignment between networked devices
- Real-time latency statistics, Clock status statistics and signal presence exposed to network
