CPLUS-V4H2HA UHD+ 4x2 HDMI Matrix with Audio Output
Please sign in so that we can notify you about a reply
This 4K6 4 by 2 Matrix provides the ability to connect up to four 4K6 HDMI sources to up to two 4K6 HDMI displays and freely switch between them. This unit comes with full support for 4K@6Hz (4:4:4, 8- bit) as well as support for 16-bit Deep Colour, HDR (High Dynamic Range), 3D content, HD audio and other features defined by HDMI 2. specification. Pre-defined internal EDIDs and external EDIDs option are available for EDID managing. The matrix also supports auto source switch and display control for power on/off the connected devices by sending CEC or RS-232 commands. Control is provided via frontpanel buttons, RS-232, and IR remote.
Features
- Supports UHD+ resolutions up to 496x216@6Hz (YUV 4:4:4, 8 bit)
- Supports 16-bit Deep Colour up to 18@6Hz
- Supports pass-through of audio formats including LPCM 2./5.1/7.1, Bitstream, and HD Bitstream
- Support internal EDIDs and external EDIDs options
- Support Auto Source Switch
- Basic signal event automation via RS-232 or CEC
Brand:
Cypress Technology
Specifications
Product Type:
HDMI Matrix with Audio
Maximum Operating Temperature:
+40°C
Colour:
Black
Control Port Type:
2xRS-32, 1xUSB 2.0 (Mini B)
Special Features:
4K UHD with Audio Output, 16bits Deep Colour, 8 Channel Audio Output, Power Automation
IR Frequency:
38kHz
Power Rating:
8.62W
Chassis Material:
Steel
Applications:
Smart Home Control, Control Center, Function Room, Product Showroom, Ball Room
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
1xUHD+, 4x2 HDMI Matrix with Audio Output, 1x5V/2.6A DC Power Adapter, 1xRemote Control (CR-190), 2x3-Pin Terminal Block, 1xShockproof Feet (Set of 4), 1xOperation Manual
Performance
Resolution:
4096x2160 pixels@50Hz/60Hz
Video Bandwidth:
18Gbps
Signal-to-Noise Ratio:
>70dB
Baud Rate:
115200bps
Total Harmonic Distortion:
<-60dB@0dBFS 1kHz
Crosstalk Level:
<-60dB
Inputs and Ports
Input Port Type:
4xHDMI Type A
Output Port Type:
2xHDMI Type-A, 1x3.5mm Stereo Audio
Number of Ports:
10
Power
Current Rating:
2.6A DC
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Length:
11.7cm
Width:
23.15cm
Height:
2.5cm
Weight:
620g
Other
Voltage Rating:
5V
Voltage Rating:
5V
Standards Met:
US/EU, CE/FCC/UL
