CMLUX-44E 4 by 4 HDMI V1.3 Matrix
Please sign in so that we can notify you about a reply
While HDMI products are getting more and more popular people are now starting to have more than one HDMI device. The HDMI V1.3 Matrix is the ideal solution for connecting all your HDMI devices, and thanks to the included remote this system gives you complete control over your media environment. Furthermore, the HDMI V1.3 Matrix can transfer Deep Color video and bit stream digital audio with maximum performance and also supports HDMI 1.3, HDCP 1.1 and DVI 1.0. Please follow this manual to begin enjoying the benefits of your HDMI 1.3 Matrix. We suggest keeping it in a safe place for future reference.
Features
- HDMI 1.3, HDCP 1.1 and DVI 1.0 Compliant
- Supports digital video formats in Deep Color Mode at up to 36 bits (12bits/ color) and a new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio and LPCM7.1.
- Has LED input source indicators for each output option
- Compatible with all HDMI sources and displays
- Supports a wide range of PC and HDTV resolutions from VGA to UXGA and 480i to 1080p
- Has RS-232 control
- IR remote controller and IR extender
- Dolby Digital, DTS digital audio transmission (32-192 kHz Fs sample rate)
- HDMI cable distance test showed that with 1080p/8-bit & 12-bit resolution, the input/ output source(s) can be up to 15/15 meters away
- High perfomance Matrix with four inputs and four outputs
- When the HDMI signal passes through the system it is Re-timed and level compensated to preserve signal
- Switchable EDID function for choosing EDID to display
Brand:
Cypress Technology
Product Type:
HDMI Matrix
Specifications
Maximum Operating Temperature:
+40°C
Colour:
Black
Special Features:
Switchable EDID Function for Choosing EDID to Display
Power Rating:
13W
Chassis Material:
Metal
Applications:
Multi-Source Input with Multi-Display Output Control, Home Entertainment Integration, Multi-task Project Presentation, Showroom Display, Advertising Display Control
Minimum Operating Temperature:
0°C
Includes:
4 by 4 V1.3 HDMI Matrix, Remote Control CR33 (with Battery), IR Receiver, 5V DC Power Supply Adaptor, Operation Manual
Performance
Resolution:
480I to 1080pixels@50Hz/60Hz, 1080pixels@24Hz, VGA to UXGA
Video Bandwidth:
2.25Gbps (Single Link)
Baud Rate:
19200bps
Inputs and Ports
Input Port Type:
4xHDMI Female Port
Output Port Type:
4xHDMI Female Ports
Number of Ports:
4x4
Power
Current Rating:
3.2A
Dimensions
Length:
14.5cm
Width:
28cm
Height:
4.9cm
Weight:
1190g
Other
Voltage Rating:
5V DC
Voltage Rating:
5V DC
Standards Met:
CE/FCC/UL Certified
