RC-43SL 6-Button Room Controller

The RC−43SL is a touch−sensitive 6−button control keypad. Connected over Ethernet to Site−CTRL™ remote AV control, site management & monitoring system, as well as LAN−connected control gateways for extended controlled devices capacity. It also connects over KNET™ to master room controller and auxiliary keypads for remote keypad control. It can flexibly serve either as a standalone room controller, part of multi−units KNET™ system, or part of multi−unit Ethernet system managed by Kramer Site−CTRL™ site management platform. The RC−43SL is ideal for auditoriums and meeting rooms, for convenient control of their complex multimedia systems and other room facilities such as screens, lighting and shades.

Features

  • Touch-Sensitive & Label Capable Buttons — 6 white-color LED-feedback buttons.
  • Custom Labeled, Removable Button Caps.
  • 1 K-NET™ Connector — Connect to master room controller, and auxiliary keypads for remote keypad control.
  • K-NET™ Single Link Connection — Provides a single keypad link cable-connectivity, carrying both power and keypad control.
  • 2 RS-232 Bi-directional Control Ports — Control a device via bi-directional serial control protocols.
  • 2 IR Emitter Control Ports — Control a device via IR control protocols.
  • 3 Relay Control Ports — Control a device via Relay Contact Closure, such as scrolling up and down screens, drapes, shades, and blinds.
  • IR Sensor Port — Learns commands from IR remotes.
  • Program Control — Program configuration with Kramer K-Config software.
  • Kramer Site-CTRL™ Compatibility — For network management and remote control over the Ethernet port.
  • Mini USB Port — To upload configuration files, set the K-NET™ ID number, and power the device during configuration.
  • Mounting — In-wall, in standard 1 gang US wall junction boxes.
  • Easy Installation — Fits to standard in-wall boxes for simple and cost-reducing installation.
Brand:
Kramer
Part number:
30-80342090
Product Type:
Ethernet Control Keypad
Specifications
Maximum Operating Temperature:
+40°C
Colour:
Black, White
Special Features:
Provides a Single Keypad Link Cable-Connectivity, Carrying both Power and Keypad Control
Control Interface Type:
6xButton
Applications:
Control in Presentation, Conference Room Systems, Board Rooms, Auditoriums
Enclosure Type:
In-Wall, Standard 1 Gang
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Includes:
Power Supply, Mounting Frame, Label Caps Set, Screwdriver
Inputs and Ports
Port Type:
2 RS-232, 1 K-NET, 1 Ethernet, 1 Infrared Sensor, 1 Mini USB
Output Port Type:
2 IR, 3 Relays
Power
Current Rating:
100mA
Dimensions
Width:
6.9cm
Depth:
3.5cm
Height:
11.4cm
Weight:
0.1kg
Other
Voltage Rating:
12V DC
Standards Met:
CE, ISO 9001:2008, ISO 9001:2008, ISO 14001:2004, OHSAS 18001:2007

RC-43SL 1 (RC-43SL.pdf, 165 Kb) [Download]

RC-43SL 2 (rc-43sl.pdf, 1,334 Kb) [Download]
