RC-206/US-D(W/B) 6-button I/O Control Keypad, US–D–size with White & Black Decora® Design Frame Sets

RC-206/US-D(W/B)

RC−206 is a compact 6−button control keypad that fits US, European and UK standard 1−gang wall junction boxes. Easy to deploy, RC−206 fits decoratively within a room design and is perfectly suited for use as a user interface keypad within a Kramer Control system. Using K−Config, tap into the rich, built−in I/O interfaces that enable this keypad to be used as a flexible, standalone room controller. In this way, it is ideal for classroom and meeting room control, providing end−user convenient control of complex multimedia systems and other room facilities such as screens, lighting and shades.Multiple keypads can be linked together side−by−side or at a distance, via a single K–NET™ cable carrying both power and communication, providing uniform design and user experience.

Features

  • Clear and Customizable User Interface — RGB–color, tactile feedback, backlit buttons with custom labeled, removable button caps, allowing simple and intuitive end–user and guest control over facility deployed devices and systems.
  • Flexible Room Control — Control any room device via LAN connections, multiple RS–232 and RS–485 serial ports, and various IR, relay and general purpose I/O built–in device ports. Connect the keypad to an IP network with additional control gateways interfacing with remote controlled devices, for extending control across large space facilities.
  • Expandable Control System — According to arising demands, easily expands to be part of a larger control system, or coupled–operation with auxiliary keypads, via either LAN or K–NET™ single cable connection delivering both power and communication.
  • Simple Control Programming — Using K–Config software. Leverage the power of Kramer’s highly customizable, flexible and user–friendly software, to easily program complex control scenarios of Pro–AV, Lighting, and other room and facility controlled devices.
  • Easy and Cost–effective Installation — Compactly fits into standard US, EU and UK 1–gang in–wall box size, allows decorative integration with room deployed user interfaces such as electrical switches.
  • Keypad installation is fast and cost–effective via single LAN cable providing both power (PoE) and communication connections.
Brand:
Kramer
Part number:
30-804925395
Product Type:
I/O Control Keypad
Specifications
Maximum Operating Temperature:
+40°C
Colour:
Black, White
Version:
US-D Version
Special Features:
Clear and Customizable User Interface, Flexible Room Control, Expandable Control System, Simple Control Programming, Easy and Cost-Effective Installation
Control Interface Type:
6xButton
Applications:
Control in Presentation, Conference Room Systems, Board Rooms, Auditoriums
Enclosure Type:
1-Gang Wall Plate, Cooling-Convection Ventilation
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Includes:
12V DC Power Adapter, Special Tweezers for Removing Button Caps, Standard Button Label Set (8.8mmx8.8mm)
Inputs and Ports
Port Type:
1xEthernet, 2xRS-232, 1xRS-485, 1xK-NET, 2 Relay, 1xGPI/O, 1xMini USB
Input Port Type:
1xIR Sensor
Output Port Type:
2 IR
I/O Interface Type:
1xGPI/O
Connectivity
Default IP Setting:
DHCP Enabled
Power
Current Rating:
2A
Dimensions
Width:
6.98cm
Depth:
4.7cm
Height:
11.4cm
Weight:
0.1kg
Other
Voltage Rating:
12V DC
Standards Met:
CE, UL Listed, RoHS, WEEE

RC-206/US-D(W/B) 1 (RC-206.pdf, 1,196 Kb) [Download]

RC-206/US-D(W/B) 2 (kramer-rc-308-rc-306-rc-208-rc-206-um-2.pdf, 1,436 Kb) [Download]
