PFS 3302 Display Interface Strip, Black, 29.5x4.1cm, For Medium to Large Size Display

Write a review
PFS 3302
Vogels
Log in to see price Add to wish list Add to Project

The PFS 3302 interface display strips is part of the modular connect-it system with which you can create your own ceiling or floor solution for medium to large sized displays;the pfs 3302 is suitable for medium to large sized displays up to 80 kg with a max. Vertical fitment of 270 mm. For creating a ceiling solution combine the pfs 3302 with a connect-it ceiling plate, pole (puc 25xx series) and interface bar (pfb 34xx series). For creating a floor solution combine the pfs 3302 with a connect-it floor plate/ trolley, pole (puc 27xx series) and interface bar (pfb 34xx series). The pfs 3302 can also be combined with the motorized products (pffe 7110, pfte 7112, pfwe 7150).

Features

  • Modular
  • Quick and Easy Installation
  • Theft Prevention
  • Tilt Function In Steps
Brand:
Vogels
Product Type:
Display Interface Strip
Specifications
Tilt Angle:
20°
Colour:
Black
Mounting Hole Pattern:
20 to 110cm (Vertical)
Series:
Connect-It
Orientation:
Portrait
For Use With:
Medium to Large Size Display
Performance
Load Capacity:
80kg
Dimensions
Width:
4.1cm
Height:
29.5cm
Shipping Weight:
1.5kg
Other
Standards Met:
TUV Certified
Warranty:
5yrs

PFS 3302 1 (7233020_PFS3302_Datasheet_Document.pdf, 78 Kb) [Download]

PFS 3302 2 (7233020_PFS3302_Leaflet_Document_EN.pdf, 197 Kb) [Download]
