iSwitch 108 4K60 1x8 HDMI splitter, smart EDID

Write a review
iSwitch 108
Infobit
Log in to see price Add to wish list Add to Project

18Gbps 1x8 HDMI Splitter is an advanced solution for splitting single HDMI signal to 8 HDMI outputs synchronously. It supports up to 18Gbps bandwidth, HDMI 2.0b/HDCP 2.2 content up to 4K@60Hz 4:4:4. It can be set the COPY/ AUTO EDID configuration.

Features
  • iSwitch 108
  • 1x8 HDMI 18Gbps Splitter
  • HDMI 2.0b, HDCP 2.2 compliant
  • Supports 18Gbps bandwidth
  • Supports resolution up to 4K@60Hz 4:4:4
  • Supports HDR function
  • Supports COPY/AUTO EDID control via dialing the dip switch
  • Compact design for easy and flexible installation
Brand:
Infobit
Product Type:
HDMI Splitter
Specifications
Audio Format:
PCM 2CH, LPCM 7.1/5.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos and DTS:X
Maximum Operating Temperature:
50°C
Colour:
Black
Supported Signals:
HDR
Power Rating:
6.15W
Chassis Material:
Metal
Applications:
UHDTV
Humidity:
20 to 90%
Minimum Operating Temperature:
-10°C
Includes:
1x18Gbps 1x8 HDMI Splitter, 1x12V/1A DC Locking Power Adapter, 1xUser Manual
Performance
Resolution:
480i to 1080pixel@50/60, 4Kx2K@24/30Hz, 4K2K@60Hz
HDMI Compliance Type:
2.0b
HDCP Compliance Type:
2.2
Frequency Rating:
50/60Hz
Inputs and Ports
Connector Type:
Input:1xHDMI Type-A (19-pin Female)/1xService Output: 8xHDMI Type-A (19-pin Female)
Number of Ports:
10
Power
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Width:
24.3cm
Depth:
10.2cm
Height:
1.6cm
Weight:
572g
Other
Voltage Rating:
100 to 240V AC (Input), 12V DC (Output)
Warranty:
3 years

iSwitch 108 1 (iSwitch-108-User-Manual_V1.0.pdf, 1,722 Kb) [Download]
