CPLUS-V8E 4K HDR 1×8 HDMI Splitter
Please sign in so that we can notify you about a reply
The 1 by 8 HDMI Splitter with HDCP 2.2 is an advanced solution for splitting a single HDMI input to 8 HDMI outputs. It provides high performance audio and video output up to 4K2K@60Hz (YUV444) resolution and is capable of provide high end of audio and video performance. This unit also support HDR (High Dynamic Range Imaging) function, which allows giving more luminance radiance contrasting and colourful pictures for better experience. It supports high resolution digital audio formats such as LPCM 7.1CH, Bitstream, HD Bitstream audio sampling rate up to 192kHz. The System Reset function allows the unit to set the TV to its default HDMI input automatically.
Features- HDMI 2.0 with 4Kx2K 6G supported, HDCP 2.2 and DVI compliant (Excludes Deep color and Color space YCbCr 422/444)
- System Reset function supported (CEC active source command
- Simultaneous displays of a single Ultra High-Definition sources on up to 8 UHDTV displays
- 3D pass-through with compatible 3D source and 3D TV
- Supports UHDTV resolutions up to 4096x2160 Note: When displaying HDMI 4Kx2K signal, equivalent source signal, output display and HDMI cables are required in order to secure the best image display
Brand:
Cypress Technology
Specifications
Product Type:
1 by 8 6G HDMI Splitter
Audio Format:
LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD
Maximum Operating Temperature:
40°C
Colour:
Black
Supported Signals:
VGA to WUXGA
Power Rating:
9.5W
Chassis Material:
Metal
Applications:
Lecture Room/Hall Presentation, Show Room/Demo Room, Public Commercial Display
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
5 V/3 A DC Power Adaptor, Operation Manual
Performance
Resolution:
480i to 1080Pixel
HDMI Compliance Type:
2
HDCP Compliance Type:
2.2
Colour Depth:
12bits or 8bits
Frequency Rating:
192kHz
Inputs and Ports
Connector Type:
HDMI, DVI, HDCP
Number of Ports:
9
Power
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Width:
24cm
Depth:
11cm
Height:
3cm
Weight:
690g
Other
Voltage Rating:
5V DC
Standards Met:
US/EU Standards, CE/FCC/UL Certified
