CPLUS-V4E 4K HDR 1×4 HDMI Splitter

Write a review
CPLUS-V4E
Cypress Technology
Out of stock
Log in to see price Add to wish list

The 1 by 4 HDMI Splitter with HDCP 2.2 is an advanced solution for splitting a single HDMI input to 4 HDMI outputs. It provides high performance audio and video output up to 4K2K@60Hz (YUV444) resolution and is capable of provide high end of audio and video performance. This unit also support HDR (High Dynamic Range Imaging) function, which allows giving more luminance radiance contrasting and colourful pictures for better experience. It supports high resolution digital audio formats such as LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD Master Audio, audio sampling rate up to 192kHz. There are input and outputs indications on panel, which will illuminate when detected, system reset function allows the unit to set the TV to it's default HDMI input.

Features
  • HDMI (with 6G audio/video support), HDCP 2.2 and DVI compliant (note: does not support 'Deep Color'/color space - YCbCr 422/444)
  • 1 HDMI input and 4 HDMI outputs
  • Supports System Reset function (CEC active source command)
  • Simultaneous display of a single Ultra High-Definition source on up to 4 UHDTV displays
  • 3D passthrough with compatible 3D source and 3D TV
Brand:
Cypress Technology
Specifications
Product Type:
1 by 4 6G HDMI Splitter
Audio Format:
LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD
Maximum Operating Temperature:
40°C
Colour:
Black
Supported Signals:
VGA to WUXGA
Power Rating:
5.4W
Chassis Material:
Metal
Applications:
Entertainment Room / Home Theater, Lecture Room/Hall Presentation, Show Room/Demo Room, Public Commercial Display
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
5 V/2.6 A DC Power Adaptor, Operation Manual
Performance
Resolution:
4096×2160Pixel@24/25/30/50/60 Hz
HDMI Compliance Type:
2
HDCP Compliance Type:
2.2
Colour Depth:
12bits or 8bits
Frequency Rating:
192kHz
Inputs and Ports
Connector Type:
HDMI, DVI, HDCP
Number of Ports:
5
Power
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Width:
23.1cm
Depth:
11.8cm
Height:
3cm
Weight:
616g
Other
Voltage Rating:
5V DC
Standards Met:
US/EU Standards, CE/FCC/UL Certified
