CLUX-4 Video Splitter, 1×4 HDMI
Please sign in so that we can notify you about a reply
These 1x4 and 1x8 HDMI splitter allow one HDMI source to connect up to four or eight HDMI displays simultaneously depends on the model. Compliant with HDMI v1.3 and HDCP v 1.1 specifications. It supports a wide range of PC resolution at up to 1600x1200px and HDTV resolutions at up to 1080p Deep colour video.
Features- HDMI 1.3, HDCP1.1 and DVI1.0 compliant
- Supports Deep colour video up to 12bit, 1080p@(24/60)Hz
Brand:
Cypress Technology
Specifications
Product Type:
1×4 HDMI Splitter
Audio Format:
Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
Maximum Operating Temperature:
40°C
Colour:
Black
Supported Signals:
VGA to UXGA
Chassis Material:
Metal
Minimum Operating Temperature:
0°C
Performance
Resolution:
480i to 1080Pixel
HDMI Compliance Type:
1.3
HDCP Compliance Type:
1.1
Colour Depth:
10bits, 12bits
Frequency Rating:
225MHz
Inputs and Ports
Connector Type:
HDMI, DVI, HDCP
Number of Ports:
5
Dimensions
Width:
10.2cm
Depth:
14.1cm
Height:
3.8cm
Weight:
550g
Other
Voltage Rating:
5V DC
Standards Met:
US/EU Standards, CE/FCC/UL Certified
