CHDMI-14 Video Splitter, 1×4 HDMI

​This HDTV distribution amplifiers are designed to make your A/V equipment more efficient, more creative and more affordable. The 1x4 HDMI distribution amplifier allows distribution to four HDMI displays using one HDMI source. Simply connect your HDMI source to the distribution amplifier input and you are ready to go. The 1x4 HDMI distribution amplifier automatically regenerates the HDMI signal for long cable runs. This is ideal for any business, educational or home use where multi-HDMI display distribution is required.

Features
  • 4 HDMI outputs
  • Signal enhancement for long cable runs
  • S/PDIF digital audio output
  • Plug in and unplug detection with front panel LED indicator lights
  • Multi-unit connection for expanded distribution
  • IR remote control and dip switch addressing
  • IR and front panel button lock out
  • Maintains 480p, 720p, 1080i and 1080p resolution
Brand:
Cypress Technology
Product Type:
1×4 HDMI Splitter
Specifications
Maximum Operating Temperature:
40°C
Colour:
Black
Supported Signals:
VGA, SVGA, XGA, SXGA, UXGA
Chassis Material:
Metal
Applications:
Business, Education or Home use
Minimum Operating Temperature:
0°C
Includes:
5V AC Power Supply, IR Remote Control, User Manual
Performance
Resolution:
480Pixel, 720Pixel, 1080Pixel, 1080iPixel
HDMI Compliance Type:
1.2
Frequency Rating:
165MHz
Inputs and Ports
Connector Type:
HDMI, DVI
Number of Ports:
5
Dimensions
Width:
21.6cm
Depth:
10.4cm
Height:
27cm
Weight:
765g
Other
Voltage Rating:
120V AC
