CLUx-8MCAT 1x8 HDMI to CAT6 Splitter
Please sign in so that we can notify you about a reply
This 1 by 8 HDMI v1.3 to single CAT6 Splitter can simultaneously distribute a single HDMI source to eight displays when connecting with a CAT6 to HDMI receiver. Providing you with an efficient and cost effective way to link your displays, this system uses a direct input of one HDMI source and eight CAT6 outputs that send uncompressed data and allow you to distribute HDMI signals at their full strength and at great distances. Moreover, this device supports 3D signals and includes an LED indicator that shows when you are broadcasting 3D media. The 1 by 8 HDMI to single CAT6 Splitter is the most efficient way to handle your HDMI splitting needs.
Features- CLUx-8MCAT1 by 8 HDMI to single CAT6 Splitter
- HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant
- Deep color video input up to 12 bits, 1080p@60Hz
- Deep color video output up to 10 bits, 1080p@60Hz
- One HDMI source to eight CAT6 output allows users to simultaneously link eight displays with eight CAT6 to HDMI receivers
- Transmit a single HDMI source through eight outputs without any signal loss
- Supports LPCM 7.1Ch, Dolby TrueHD, Dolby Digital Plus and DTS-HD
- Master Audio transmission (Sample Rate: 32-192kHz)
- Supports a wide range of PC and HDTV resolutions from VGA to WUxGA(1920x 1200) and 480i to 1080p
- Selectable EDID from either the TV or STD mode
- Deep color setting of 8 bits or 12 bits
- Supports 3D signals with an LED indicator
Brand:
Cypress Technology
Specifications
Product Type:
HDMI Splitter
Audio Format:
PCM 2CH
Maximum Operating Temperature:
+40°C
Colour:
Black
Supported Signals:
VGA to WUXGA
Power Rating:
10W
Chassis Material:
Metal
Applications:
Simultaneously Connect to Eight HDMI Displays with a CAT6 to HDMI Receiver, Showroom Displays, Advertisement Display Control, System Installation Control, Educational or Presentation Display
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
LED Indicator
Performance
Resolution:
VGA to WUXGA (1920x1200), 480i to 1080pixels
HDMI Compliance Type:
1.3
HDCP Compliance Type:
1.1
Colour Depth:
10bits
Frequency Rating:
2.25MHz (Video)
Inputs and Ports
Connector Type:
HDMI, CAT6
Number of Ports:
9
Power
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±6kV (Contact Discharge)
Dimensions
Width:
24cm
Depth:
2.5cm
Height:
10.3cm
Weight:
665g
Other
Voltage Rating:
5V DC
Voltage Rating:
5V DC
