CHDBR-2HE 1x2 HDBaseT to HDMI Splitter with Bi-directional 24V PoC and LAN Serving
Please sign in so that we can notify you about a reply
The CAT5e/6/7 over HDMI Receiver accepts from the Transmitter unit the signal of resolutions up to 1080p Full HD, 4Kx2K timing, 3D and multi-channel digital audio formats and sends to two HDTV outputs. The HDMI can be connected to HDMI display for instant nearby display and the CAT5e/6/7 can be connected to CAT5e/6/7 to HDMI Transmitter for distance up to 100 meters with Bidirectional PoE feature. Further, a total of 100Mbps Ethernet transmission rate allows all connected device to share the Ethernet service and Bidirectional PoE provides PoE to the Transmitter or received from compatible PoE Transmitter through CAT5e/6/7.
Features
- HDMI (with 3D format and 4K2K resolution support), HDCP and DVI compliant
- Dual simultaneous HDMI outputs
- Supports data rates from 250 Mbps up to 3 Gbps
- Supports a wide range of resolutions - PC from VGA to WUxGA and HDTV up to 4K2K (3840×2160@30 Hz and 4096×2160@24 Hz)
- Supports pass-through of high-definition audio formats - LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
- Supports audio sampling rates from 32 kHz to 192 kHz
- Supports distances up to 100 meters through CAT5e/6/7 cables
- Supports Ethernet transmission rate up to 100 Mbps
- Supports bi-directional IR pass-through
- Supports RS-232 control pass-through
- Supports bi-directional 24V PoC (Power over Cable) with compatible transmitter
Brand:
Cypress Technology
Specifications
Product Type:
HDBaseT/HDMI Splitter
Maximum Operating Temperature:
+40°C
Colour:
Black
Supported Signals:
UHD
Power Rating:
10W
Chassis Material:
Metal
Applications:
Household Entertainment Sharing and Control, Lecture Room Display and Control, Showroom Display and Control, Meeting Room Presentation and Control, Classroom Display and Control
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Performance
Resolution:
1080pixels Full HD, 4Kx2K Timing, 3D, Multi-Channel Digital Audio Formats, Sends to Two HDTV Output
HDMI Compliance Type:
2.0
HDCP Compliance Type:
2.2
Inputs and Ports
Connector Type:
CAT5e/6/7
Number of Ports:
8
Power
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Width:
10cm
Depth:
19.2cm
Height:
3.5cm
Weight:
282g
Other
Voltage Rating:
24V DC
Voltage Rating:
24V DC
Standards Met:
US/EU Standards, CE/FCC/UL Certified
