221R1029-01 MultiView 9D, 1x9 CAT5 Cascadable Distribution Amplifier supports up to 1920x1200
Please sign in so that we can notify you about a reply
A key component for point to multi-point applications, the MultiView 9D splits the UTP output from any MultiView transmitter into 9 UTP outputs that can be connected to MultiView receivers, daisy chain of receivers, distribution amplifiers, or matrix switchers. The MultiView 9D supports all MultiView TX and RX devices and sustains the resolution and distance capabilities of the receivers when splitting the UTP signals.
Features- Splits one UTP input into 9 UTP outputs
- May be used individually, cascaded or tiered to as many as 729 displays
- Supports all MultiView-‘X’ functionality versions
- Compatible with all MultiView transmitters, receivers, DA’s and matrix switchers
- Enables extension of 1920x1200 resolution video from 1 to 2000ft/609m
- All same-source displays retain perfect sync
- High-reliability design suitable for harsh environments
- Optional mount kits and mini-dense power supplies for rack-mount/rigid installations
Brand:
tvONE
Product Type:
UTP Splitter
Specifications
Video Signal Format:
DVI-D, HDMI, RGBHV, RGBS, RgsB, RsGsBs, Component Video 6, S-Video 5 & Composite Video 5
Maximum Operating Temperature:
+40°C
Special Features:
RepliSync Technology, Cascading, Daisy-Chaining
Indicator Type:
LED
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Performance
Input Impedance Rating:
600Ω (Audio), 75Ω (Video)
Inputs and Ports
Connector Type:
3.5mm Audio-In, HD15-F, RJ45, Phoenix, DB9-M
Power
Input Voltage:
5V DC
Output Impedance Rating:
75Ω (Video), 600Ω (Audio)
Dimensions
Width:
21cm
Depth:
16.5cm
Height:
4.4cm
Weight:
1kg
Other
Standards Met:
CE, FCC Class A, IC Class A, RoHS
