CLUX-DDP DVI to DVI Enhancer with EDID Management
Please sign in so that we can notify you about a reply
The DVI Enhancer with EDID Management is a handy device for your DVI signal extension and differentiation. This device Could access EDID management program, which allows user to upload EDID for selection which create alternative EDID selection for specific usage. Last but not least, EDID select button and LEDs design allow fast switching and quick viewing on the status.
Features
- DVI supported, HDCP and HDMI compliant
- Supports EDID selection from internal, external and user’s EDID to be insert
- Supports EDID Manager application control via USB
- LEDs display with fast viewing on current selection status
- USB firmware update
Brand:
Cypress Technology
Product Type:
DVI to DVI Enhancer
Specifications
Cable Length:
5m@4K2K/60Hz-YUV420, 10m@1080p/12bits, 15m@1080p/8bits
Maximum Operating Temperature:
+40°C
Colour:
Black
Power Rating:
1.32W
Chassis Material:
Metal
Humidity:
20 to 90%
Minimum Operating Temperature:
0°C
Includes:
1xDVI Enhancer with EDID Management, 1x5V/2.6A DC Power Adaptor, 1xOperation Manual
Performance
Resolution:
VGA, WUXGA (RB), 480i, 1080pixels@24Hz/50/60Hz, 4K2K@24Hz/25/30/50/60Hz (YUV420)
Bandwidth:
9Gbps
Inputs and Ports
Input Port Type:
1xDVI, 1xmini-USB (Service)
Output Port Type:
1xDVI
I/O Interface Type:
1xMini-USB (Service)
Power
Current Rating:
2.6A
ESD Protection Rating:
±8kV (Air-Gap Discharge), ±4KV (Contact Discharge)
Dimensions
Width:
7.85cm
Depth:
8.4cm
Height:
3cm
Weight:
146g
Other
Voltage Rating:
5V DC
Standards Met:
CE, FCC Compliant, UL Listed
