KDS-EN4 Encoder/Streamer
Please sign in so that we can notify you about a reply
KDS−EN4 is an H.264 encoder for HDMI signals of up to 1920x1080p@60Hz. It provides high−quality and fully−featured end−to−end video and audio over IP. KDS−EN4 includes AVC support for H.264/MPEG−4 and AAC codec, open encoding that enables decoding through VLC® player software and unicast or multicast streaming through RTSP.
Features
- High Resolution Video Encoding and Compression - supporting the following resolutions: 1080p@60Hz (on the decoder only), 1080p@30Hz, 720p@60Hz, and 720p@30Hz.
- Maximum Compatibility - Fully standard and compliant H.264/MPEG-4 AVC (Advanced Video Codec) and AAC (Advanced Audio Code) codecs, enable compatibility with other software and hardware encoders. Open encoding enables software decoding through VLC® player software.
- Flexible Audio Support - Embedded HDMI and unbalanced analog stereo line in for both the encoder input and decoder output.
- Standard Ethernet Network Operation - 10/100/1000Mb.
- Selectable Streaming Mode - Unicast or multicast through RTSP (Real Time Streaming Protocol).
- Customizable Recording - Store streaming sessions on a computer or external USB storage appliance.
- Powerful, Versatile and User-friendly Device Management - Manage device operation and settings, using Kramer Network Enterprise Management Platform.
- Flexible Operation - Operate the unit by RS-232 remote control or through the embedded web pages. Control an external device via the RS-232 DATA port.
- Easy Installation - Compact DigiTOOLS® fan-less enclosure for dropped-ceiling mounting, or side-by-side mounting of 3 units in a 1U rack space with the optional rack adapter.
Brand:
Kramer
Part number:
60-00003290
Product Type:
Encoder/Streamer
Specifications
Maximum Operating Temperature:
+40°C
Streaming:
Unicast and Multicast through RTSP (Real Time Streaming Protocol)
Recording File Format:
USB Storage
Special Features:
Flexible Audio Support-Embedded HDMI and unbalanced analog stereo linein for both the Encoder input and Decoder output, Standard Ethernet Network Operation-10/100/1000Mb
Applications:
Education E-Learning with Multicast live Streaming on campus and Over the internet, Boardroom Enhancements-Sharing Content from Boardrooms with Remote Participants, Digital Signage-Mass Distribution of Content to many Screens with no limit on Distance, Ho
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Includes:
Power Supply, Bracket Set
Performance
Video Resolution:
1080pixels@60Hz (on the Decoder Only), 1080pixels@30Hz, 720pixels@60Hz, 720pixels@30Hz
Bit Rate:
128Kbps
Audio Sample Rate:
44.1kHz, 48kHz
Inputs and Ports
Audio Input Type:
3.5mm Mini Jack
Power
Current Rating:
800mA
Dimensions
Width:
12.cm
Depth:
7.1cm
Height:
2.4cm
Weight:
0.5kg
Other
Voltage Rating:
5V DC
Voltage Rating:
5V DC
