Hdb2920i-NA ZeeVee Encoder/RF Modulator, RJ45, 2 (SDI)
Please sign in so that we can notify you about a reply
For organizations looking to encode and modulate unencrypted HDMI sources cost-effectively, the HDBridge 2900 Series is a great option. This four channel encoder/modulator allows you to deliver HD video up to 1080p/i resolution to an unlimited number of displays over almost any distance. The HDbridge 2900 series converts high definition AV sources into an RF signal received a television's QAM (NA model) or DVB-T/C (EU model) digital tuner over coax cable. With its high 45 dBmv RF output, you can send your content to an unlimited number of displays over nearly any distance.
Features
- SUPERIOR VIDEO QUALITY: Full MPEG-2 implementation;I, P, and B Frames;Low latency;Full motion estimation with a wide search range
- EASE OF MANAGEMENT: Powerful, highly intuitive web interface;On-site or remote management;Configure/manage multiple units from;Front Panel Display for local management
Brand:
Kramer
Product Type:
Encoder/RF Modulator
Specifications
Maximum Operating Temperature:
45°C
Series:
ZeeVee
Storage File System:
MPEG2
Control Interface Type:
RJ45
Applications:
Education, Government, Hospitality, Retail, Sports, Entertainment, Broadcasting, Healthcare, Housing, Energy and Other Industries
Humidity:
10 to 80%
Minimum Operating Temperature:
0°C
Includes:
Rack Ear, Power Cord
Performance
Video Resolution:
1080p/i
Resolution:
2kHz
Video Encoding Type:
MPEG2 HD: ISO13818-2 Main Profile@HighLevel
Bit Rate:
18Mbps
Audio Encoding and Bitrate:
AC-3, ATSC A/52
Inputs and Ports
Audio Input Type:
Digital Audio, Stereo Analog
Video Input Type:
2 (SDI)
Input Port Type:
Digital Audio, Stereo Analog
Output Port Type:
RF
Interface Type:
10Mb, 100Mb
Power
Power Source Type:
External Power Supply
Dimensions
Width:
44cm
Depth:
25.1cm
Height:
4.3cm
Weight:
2.9kg
Shipping Weight:
3.6kg
Other
Voltage Rating:
100 TO 240V AC
Standards Met:
FCC Class A, IEC60065, EN61000, CE, RoHS, RCM C-Tick, TAA Compliant
