PT-1C EDID Processor
Please sign in so that we can notify you about a reply
PT−1C is a 4K HDR EDID processor. It allows you to lock EDID signals and to support or not support HDCP, multi−channel audio or deep color signals that may or may not be compatible with the display.
Features
- Max. Data Rate - 17.82Gbps (5.94Gbps per data channel).
- Max. Resolution - 4K@60Hz (4:4:4).
- HDMI Compatible.
- Compliance with HMDI Standards - HDR10, HDCP 2.2.
- Line Powered Device - Power taken from the HDMI line, no power supply is needed.
- Indicator - Power LED.
- Controls - Four program DIP-switches control desired functions.
Brand:
Kramer
Part number:
60-80223099
Specifications
Product Type:
HDMI EDID Processor
Maximum Operating Temperature:
+40°C
Control Type:
4-Position DIP Switch
Indicator Type:
LED
Humidity:
10 to 90%
Minimum Operating Temperature:
0°C
Performance
HDMI Compliance Type:
2.2
HDCP Support (Yes/No):
Yes
Data Transfer Rate:
17.8Gbps
Maximum Resolution:
4K@60Hz (4:4:4)
Inputs and Ports
Input Port Type:
1xHDMI
Output Port Type:
1xHDMI
Dimensions
Width:
6.22cm
Depth:
5.1cm
Height:
2.4cm
Weight:
0.1kg
Other
Standards Met:
ISO 9001
No reviews found
